Homeowner's Manual
H6
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious
injury, death, or property damage.
Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
▪
DANGER
4009372-01
Direct Vent Gas Fireplaces
natural gas 1400MN
propane gas 1400MP
▪
▪
▪
▪
Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
Hot glass
will cause burns.
Do not touch glass
until cooled.
Never allow children
to touch glass.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fi re department.
A barrier designed to reduce
the risk of burns from the hot
viewing glass is provided with this
appliance and must be installed for
the protection of children and
other at-risk individuals.
Advertisement
Table of Contents
Related Manuals for Valor 1400MN
Summary of Contents for Valor 1400MN
- Page 1 Homeowner’s Manual Direct Vent Gas Fireplaces natural gas 1400MN propane gas 1400MP Do not touch any electrical switch; do ▪ WARNING: not use any phone in your building. FIRE OR EXPLOSION HAZARD Leave the building immediately. ▪ Failure to follow safety warnings Immediately call your gas supplier from ▪...
- Page 2 Ltd. reserves the right to change or modify any information or specifications without notice. Miles Industries Ltd. grants no warranty, implied or stated, for the installation or maintenance of your heater, Valor Fireplaces and assumes no responsibility for any consequential 190–2255 Dollarton Highway damage(s).
-
Page 3: Table Of Contents
Getting started ............7 Your valor fi replace First time operation............7 Here are some important details about your Valor Locating fi replace and lighting information ..... 7 fireplace, should you need to contact your dealer. Parts of your fi replace ..........8 Model: _________________________________________ Operating your fi... -
Page 4: Safety And Your Fireplace
Read and understand all instructions carefully before operating your fi replace. Failure to follow these instructions may result in possible fi re hazard and will void the warranty. Replacement manuals are available by contacting Valor Customer Service at 1-800-468-2567, or by visiting valorfi... - Page 5 Safety and your fireplace Glass window Initial and annual inspection • The glass window fronts must be in place and sealed • Installation and repair should be performed by before the unit can be placed into safe operation. a qualifi ed service person. The appliance should be inspected before use and at least annually by a •...
-
Page 6: Child Safety And Your Fireplace
Read and carefully follow all safety warnings and operating instructions contained in this manual, and follow these important child safety precautions and recommendations: • Parts of your Valor Fireplace become extremely A physical barrier is recommended if there are hot while in operation. The glass window tempera- at-risk individuals in the house. -
Page 7: Getting Started
flames will be at their normal height. Valor automatic gas shut-off For your safety, Valor fireplaces are fitted with a flame supervision device which will shut-off the gas supply if, for any reason, the pilot flame goes out. -
Page 8: Parts Of Your Fireplace
Parts of your fireplace Here are the major components of your installed fireplace, with the protective barriers installed. Your individual fireplace may appear differently depending on your installed options. Barrier Screen Trim Liner Panels Fuel Bed Side Doors Burner Plaque Window Frame Decorative Lighting Trim... -
Page 9: Operating Your Fireplace
Appendix A—Remote control the fireplace - see page 7 to learn how to access it. operation on page 28 of this manual or visit Also, a copy of this card is reproduced in Appendix A valorfireplaces.com/remotes of the Installation Manual. -
Page 10: Preventing Inadvertent Ignition
Automatic shut-off (in certain conditions) Your fireplace’s remote control is equipped with an automatic shut-off mechanism which is activated in certain conditions. See Appendix A—Remote control operation on pages 23-29 or go to valorfireplaces. com/remotes for a description of this feature. -
Page 11: Replacing Batteries
Replacing batteries To replace the batteries: WARNING 1. Remove the used batteries from the battery holder and replace with 4 new AA 1.5V alkaline Do not attempt to access the batteries batteries. Do not mix old and new batteries! while the fi replace is hot! Let the fi... -
Page 12: Replacing Light Bulbs
Replacing light bulbs Decorative Lighting Replacing Light Bulbs This appliance is equipped with decorative lighting We recommend replacing both light bulbs at the same located above the window. time. The Decorative Lighting is operated by the remote WARNING control—see Appendix A—Remote control operation on page 25. -
Page 13: Annual Service And Maintenance
Annual service and maintenance We recommend having your fi replace serviced before initial use, and at least once per year by a qualifi ed service technician. Contact your dealer quoting the model serial number, if possible. It will be helpful if the fi replace’s serial number can also be quoted. -
Page 14: Cleaning Your Fireplace
Cleaning your fireplace 4. Locate the window latch pull handle on the bottom of the fi replace. It is held in place by Velcro. Pull it WARNING out. Risk of severe burns! Do not touch the glass while it is hot! Let the fi replace cool fi... - Page 15 Log position » Brasso, Polish Plus by KelKem, Cook Top Clean Log position is important in your Valor fireplace Creme by Elco, White Off by Rutland, Turtle Wax because it can optimize the beauty of the flame and the combustion efficiency of your fireplace.
-
Page 16: Reinstall And Check Window
• Damage components. • Cause overheating resulting in dangerous conditions. Damage caused by incorrect window installation is not covered by the Valor Warranty. 2. Using the latch pull handle, hook the four spring latches over the corresponding tabs as shown. - Page 17 Cleaning your fireplace 3. Pull and release the top and bottom of the window 8. Re-install the side doors, sliding them in the slots to ensure the springs return it. behind the front panel of the trim and pushing them down. 4.
-
Page 18: Checking Pilot And Burner Flames
Checking pilot and burner flames Typical fl ame appearance - H6 The pilot light and burner flames should be checked periodically. Check after the fire has been on for at Driftwood Logs least 30 minutes. The pilot flame must cover the tip of the thermocouple probe. -
Page 19: Frequently Asked Questions
If the fireplace still won't turn on after that, call your dealer for further information. Your fireplace may require service by a qualified service technician. Visit valorfireplaces.com/contact for a list of dealers near you. I've just started my fi replace When operating your fireplace for the first time, some vapors may... - Page 20 Where can I purchase parts Any of our Valor dealers are able to order parts or provide field service. for my fi replace? Please contact your dealer - see page 3 - or visit valorfireplaces.com/ contact for a list of dealers near you.
-
Page 21: Valor ® Warranty
Installation and maintenance must be performed by 5. No Other Warranty an authorized and trained dealer in accordance with All obligations to repair this unit are de ned in this warranty. -
Page 22: Valor ® Outdoor Installation Warranty
The Company does not allow anyone to extend, b) Installation and maintenance must be performed alter or modify this warranty and assumes no... -
Page 23: Appendix A-Remote Control Operation
Appendix A—Remote control operation Remote Control Operation Note: Before using the remote control system for the first time, the receiver and the handset must be paired. NOTE: Before using the remote control system for the first time, the receiver and the handset must be paired. See See the Remote Control Setup section in the Installation Manual. - Page 24 Appendix A—Remote control operation Designated Low Fire and High Fire To deactivate functions: To go to low re, double-click . “LO” 1. Install batteries. All icons are displayed and ashing. is displayed. 2. While the icons are ashing, press the relevant func- tion button and hold for 10 seconds.
- Page 25 Appendix A—Remote control operation Child Proof Light/Dimmer Operation Your handset can be set to lock out all commands to the replace, except OFF. Press is displayed. Light is on at preset level. To turn Child Proof ON: 1. Press and hold simultaneously.
- Page 26 Appendix A—Remote control operation Modes of Operation Thermostatic Mode Thermostatic Mode The room temperature is measured and Press . is displayed. Preset compared to the set temperature. The temperature displays brie y, followed ame height is automatically adjusted by the room temperature. to achieve the set temperature.
- Page 27 Appendix A—Remote control operation Temperature Setting: Off Time Setting (PROGRAM 1) , 1, OFF 1. Press and hold until ashes. are displayed. ALL is ON and set temperature (set in Ther- displayed brie y. Hour ashes. mostatic Mode) is displayed. 2.
- Page 28 Appendix A—Remote control operation Low Battery Indication Low Battery Receiver With low battery power in the battery holder, the system shuts o the re completely. (This will not CAUTION: Do not use a screwdriver or other happen if the power is completely interrupted.) metallic object to remove the batteries from the battery holder or the handset.
- Page 29 Appendix A—Remote control operation Error Codes In the event of an error condition with the handset or replace, the handset will display an error code. Failure Message on Duration of Symptom Possible Cause Code Handset Display 4 sec • No pilot ame within 30 sec •...
-
Page 30: Appendix B-Wall Switch Operation
Appendix B—Wall switch operation The Wall Switch can be used to Adjusting Flame Height control your fireplace. You can Press and hold large flame button turn the pilot on or off and you can to gradually increase flame height. increase or decrease the flame height. Note that the thermostat and programming functions are not available with the wall switch.
