Homeowner's Manual
H5
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious
injury, death, or property damage.
Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
▪
DANGER
4008356-01
Direc Vent Gas Fireplaces
natural gas 1100MN
propane gas 1100MP
▪
▪
▪
▪
Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
Hot glass
will cause burns.
Do not touch glass
until cooled.
Never allow children
to touch glass.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fi re department.
A barrier designed to reduce
the risk of burns from the hot
viewing glass is provided with this
appliance and must be installed for
the protection of children and
other at-risk individuals.
Advertisement
Table of Contents
Related Manuals for Valor H5 1100MN
Summary of Contents for Valor H5 1100MN
- Page 1 Homeowner’s Manual Direc Vent Gas Fireplaces natural gas 1100MN propane gas 1100MP Do not touch any electrical switch; do ▪ WARNING: not use any phone in your building. FIRE OR EXPLOSION HAZARD Leave the building immediately. ▪ Failure to follow safety warnings Immediately call your gas supplier from ▪...
- Page 2 This appliance may be installed in an after-market permanently located, manufactured (mobile) home where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certifi...
-
Page 3: Table Of Contents
fi replace, do not try to repair the unit yourself. Contents Your Valor Fireplace Safety and your fi replace .......... 4 Here are some important details about your Valor Child safety and your fi replace ......... 6 fi replace, should you need to contact your dealer. Model: _________________________________________ Getting started ............ -
Page 4: Safety And Your Fireplace
Read and understand all instructions carefully before operating your fi replace. Failure to follow these instructions may result in possible fi re hazard and will void the warranty. Replacement manuals are available by contacting Valor Customer Service at 1-800-468-2567, or by visiting valorfi... - Page 5 Safety and your fireplace Barrier Screen and Safety Maintenance • Keep the unit’s control compartment, burner, and • A barrier designed to reduce the risk of burns from circulating air passageways clean to enable ad- the hot viewing glass is provided with this appli- equate combustion and ventilation air.
-
Page 6: Child Safety And Your Fireplace
Read and carefully follow all safety warnings and operating instructions contained in this manual, and follow these important child safety precautions and recommendations: • Parts of your Valor Fireplace become extremely A physical barrier is recommended if there are hot while in operation. The glass window tempera- at-risk individuals in the house. -
Page 7: Getting Started
fl ames will be at their normal height. Valor automatic gas shut-off For your safety, Valor fi replaces are fi tted with a fl ame supervision device which will shut-off the gas supply if, for any reason, the pilot fl ame goes out. -
Page 8: Parts Of Your Fireplace
Parts of your fireplace Here are the major components of your installed fireplace, with the protective barriers installed. Your individual fireplace may appear differently depending on your installed options. Barrier Screen Window Frame Trim Liner Panels Fuel Bed Side Door— Fireplace info card behind right door Burner Plaque... -
Page 9: Operating Your Fireplace
Fireplace and Lighting Information card attached to Operation on page 27 of this manual or the fi replace - see page 7 to learn how to access it. visit valorfi replaces.com/remotes Also, a copy of this card is reproduced in Appendix A of the Installation Manual. -
Page 10: Preventing Inadvertent Ignition
Automatic shut-off (in certain conditions) Your fi replace’s remote control is equipped with an automatic shut-off mechanism which is activated in certain conditions. See Appendix A-Remote Control Operation on pages 22-28 or go to valorfi replaces.com/remotes for a description of this feature. -
Page 11: Replacing Batteries
Replacing batteries To replace the batteries: WARNING 1. Remove the used batteries from the battery holder and replace with 4 new AA 1.5V alkaline Do not attempt to access the batteries batteries. while the fi replace is hot! Let the fi... -
Page 12: Annual Service And Maintenance
Annual service and maintenance We recommend having your fi replace serviced before initial use, and at least once per year by a qualifi ed service technician. Contact your dealer quoting the model serial number, if possible. It will be helpful if the fi replace’s serial number can also be quoted. -
Page 13: Cleaning Your Fireplace
Cleaning your fireplace WARNING Risk of severe burns! Do not touch the glass while it is hot! Let the fi replace cool fi rst before cleaning it. Remove Window The window is held in place by 4 spring-loaded latches on each side of the fi rebox. 1. - Page 14 Log position » Brasso, Polish Plus by KelKem, Cook Top Clean Log position is important in your Valor fi replace Creme by Elco, White Off by Rutland, Turtle Wax because it can optimize the beauty of the fl ame and the combustion effi...
- Page 15 • Cause overheating resulting in dangerous conditions. Damage caused by incorrect window installation is not covered by the Valor Warranty. 3. Pull and release the top of the window to ensure the spring-loaded mechanism returns the win- dow to the fi rebox. Repeat with the bottom of the window.
- Page 16 Cleaning your fireplace 5. If the Hot Glass Warning plate has been removed from the front lower corner of the window, reinstall it by sliding it between the glass and the frame as indicated. Hot Glass Warning Plate 6. Re-install the side doors. 7.
-
Page 17: Checking Pilot And Burner Flames
Checking pilot and burner flames Typical fl ame appearance - H5 The pilot light and burner fl ames should be checked periodically. Check after the fi re has been on for at Driftwood Logs least 30 minutes. The pilot fl ame must cover the tip of the thermocouple probe. -
Page 18: Frequently Asked Questions
If the fi replace still won't turn on after that, call your dealer for further information. Your fi replace may require service by a qualifi ed service technician. Visit valorfi replaces.com/contact for a list of dealers near you. I've just started my fi replace When operating your fi... - Page 19 Where can I purchase parts Any of our Valor dealers are able to order parts or provide fi eld service. for my fi replace? Please contact your dealer - see page 3 - or visit valorfi...
-
Page 20: Valor ® Warranty
Installation and maintenance must be performed by 5. No Other Warranty an authorized and trained dealer in accordance with All obligations to repair this unit are de ned in this warranty. -
Page 21: Valor ® Outdoor Installation Warranty
The Company does not allow anyone to extend, b) Installation and maintenance must be performed alter or modify this warranty and assumes no... -
Page 22: Appendix A-Remote Control Operation
Appendix A-Remote Control Operation Remote Control Operation Note: Before using the remote control system for the first time, the receiver and the handset must be paired. NOTE: Before using the remote control system for the first time, the receiver and the handset must be paired. See See the Remote Control Setup section in the Installation Manual. - Page 23 Appendix A-Remote Control Operation Designated Low Fire and High Fire To deactivate functions: To go to low re, double-click . “LO” 1. Install batteries. All icons are displayed and ashing. is displayed. 2. While the icons are ashing, press the relevant func- tion button and hold for 10 seconds.
- Page 24 Appendix A-Remote Control Operation Child Proof Light/Dimmer Operation Your handset can be set to lock out all commands to the Not available on this appliance. replace, except OFF. Press is displayed. Light is on at preset level. To turn Child Proof ON: 1.
- Page 25 Appendix A-Remote Control Operation Modes of Operation Thermostatic Mode Thermostatic Mode The room temperature is measured and Press . is displayed. Preset compared to the set temperature. The temperature displays brie y, followed ame height is automatically adjusted by the room temperature. to achieve the set temperature.
- Page 26 Appendix A-Remote Control Operation Temperature Setting: Off Time Setting (PROGRAM 1) , 1, OFF 1. Press and hold until ashes. are displayed. ALL is ON and set temperature (set in Ther- displayed brie y. Hour ashes. mostatic Mode) is displayed. 2.
- Page 27 Appendix A-Remote Control Operation Low Battery Indication Low Battery Receiver With low battery power in the battery holder, the system shuts o the re completely. (This will not CAUTION: Do not use a screwdriver or other happen if the power is completely interrupted.) metallic object to remove the batteries from the battery holder or the handset.
- Page 28 Appendix A-Remote Control Operation Error Codes In the event of an error condition with the handset or replace, the handset will display an error code. Failure Message on Duration of Symptom Possible Cause Code Handset Display 4 sec • No pilot ame within 30 sec •...
- Page 29 Appendix B-Wall Switch Operation The Wall Switch can be used to Adjusting Flame Height control your fi replace. You can Press and hold large fl ame button turn the pilot on or off and you can to gradually increase fl ame height. increase or decrease the fl...
- Page 30 Notes...
