1195CFK CIRCULATING FAN KIT
CSA approved for use only with Valor models 1100, 1150 and 1400 Series Heaters
Installation and Operating Instructions
Note: This kit must be installed or serviced by a qualifi ed installer, service agency or gas supplier.
These instructions are to be used in conjunction with the main installation instructions for the above
listed models.
WARNING: If these instructions are not followed exactly, a fi re or explosion may result
causing property damage, personal injury or loss of life.
GROUNDING: This power supply must be installed and grounded in accordance with local codes,
or in the absence of local codes, with the current Canadian Electrical Code CSA C22.1. or in the
USA the National Electrical Code ANSI/NFPA70 latest edition.
Description of System
The models listed above have been designed to ac-
commodate the installation of an air circulation fan.
Operated via the remote control handset and having
variable speed control, the fan is designed to boost the
natural convection through the heater; this may be a
desirable feature dependent on the fi replace location
and room layout.
It is preferable to install the circulating fan before
completing the heater installation although it may
also be retrofi tted at a later date provided power has
been pre-wired within the fi replace casing.
Note: Live wiring must terminate within a junction box.
A junction box is supplied as part of this kit. If roughing-
in power ahead of the fan installation, ensure the wiring
is not live or terminate within a temporary junction box.
Retrofi tting the fan after the fi replace installation is
completed will require disconnecting the gas and
removing the burner module and gas train from the
fi replace.
The fan is designed for automatic operation to come
on and off when the burner comes on and off. The fan
speed can be controlled from the remote control hand-
set. There are four speeds available. The fan, if turned
on, will start approximately 4 minutes after lighting the
appliance and will continue to run for approximately 10
minutes after the burner is shut off. The fan will operate
at the speed last selected by the user.
4004422-03
© 2015, Miles Industries Ltd. All rights reserved.
H5 & H6
Operation
To operate the fan, press the
handset; the fan icon
the
and
buttons to set the fan speed. No bar
showing means the fan is OFF. Press the
to confi rm the setting or wait. The fan icon and number
of bars will show when the remote is in other modes to
confi rm the fan status.
Note: The fan, when plugged in, provides power for
the remote control receiver via the fan control module.
Therefore batteries are no longer required in the
receiver other than for back-up purposes. Batteries
are still required in the remote control handset.
Electrical Requirements
The fan kit requires a power supply of 120 Volts,
1 phase, 60 Hz. Full load current is less than 1 amp.
button on the remote
fl ashes on the display. Press
button
1
