Valor L1 Installation And Upgrades

INSTALLATION MANUAL
For Valor L1, L1 See Thru, L2, L3, LT1, LT2 , LX1, LX2, H5, H6, and P2 Heaters
Introduction
The Valor L1, L1 See Thru, L2, L3, LT1, LT2, LX1, LX2,
H5, H6 and P2 fi replaces may be upgraded with a
WiFi module, allowing the homeowner to connect the
fi replace onto the home's WiFi system and control it
using the Valor 10 app on a smart device (which must
be within WiFi range).
There are separate general requirements for each
major style of fi replace. Make sure to follow the
instructions for each style.
Electrical Requirements
A grounded, single phase, 115VAC power supply is
required for operation of the WiFi system.
If the AC main power is lost, WiFi operation will be
lost also. Remote operation of the fi replace (using the
remote handset or wall switch) can still be achieved if
battery power is already supplied and available.
WARNING
All electrical installations must be
performed by a qualified electrician and
must be electrically wired and grounded
in accordance with local codes, or, in the
absence of local codes, with the National
Electrical Code, ANSI/NFPA 70 or the
Canadian Electrical Code, CSA C22.1.
Attention!
If the AC receptacle in your fi replace has not
been connected, see your Installation Manual for
instructions, or hard wire back to available power
(consult local electrical codes).
4007703
Apr 2024
WIFI UPGRADES
Table of Contents
Hardware Specifi cations ...................................................2
Wiring Diagram...................................................................4
H5/6 Power Kit (H5/6-WPK) ..............................................5
P2 Power Kit (P2-WPK) ......................................................6
V-Module Kit (GV60VM) .....................................................7
Linear Models ................................................................... 7
H5 and H6 Models ........................................................... 8
P2 Models ......................................................................... 9
Remote Kit (RCK400) ........................................................10
After Installation ..............................................................12
Caution
When installing any cables or wires in the steps
listed, be sure to gather any extra wire with cable
ties and prevent them touching the fi rebox or other
hot metal surfaces in the fi replace!
1
