Control Drawing

Hazardous (Classified) Location
Class I, II, III, Division 1, Groups A,B,C,D,E,F,G
Class I, Zone 1, Groups IIA, IIB, IIC
Zone 21
Display Unit of the
SIWXS...-3-..-...
7)
SARTORIUS
Weighing Unit
Series
SIWXS...-3-..-...,
SIWXS...-3-V...,
ISX...-..-... and
ISX...-V...
WARNING:
SIWXSBBP-3-06-H.. ,
ISXBBP-06-H.. and all ...-V1..
models may not be used in
Class II, III, Groups E,F,G
and in Zone 21, respectively!
Data Interface Board
5)
11)
T-Connector
5)
13)
Any NRTL approved equipment with
Entity Concept parameters
E.g. SARTORIUS Indicator
CIXS3-.
CAIXS2-....
2013-12-12
Dr. D. Klausgrete
114 Signum 3 Ex
5)
6)
3)
8)
9)
10)
5)
10) or 12)
9)
3)
14)
20)
Hazardous (Classified) Location
Class I,II,III, Division 1,
Groups A,B,C,D,E,F,G
Canada: Group A is excluded!
SARTORIUS
Power Supply Type
4)
19)
YPS02-XUR
18)
YPS02-XKR
Hazardous (Classified) Location
Class I,II,III, Division 2,
Groups A,B,C,D,E,F,G
Class I, Zone 1, Groups IIA, IIB
Class II, Zone 21
SARTORIUS
4)
Rechargeable
Battery Pack
17)
YRB02-X
Non-Hazardous Location
SARTORIUS
4)
Power Supply Type
16)
YPS02-XKR
Any NRTL approved
equipment with Entity
Concept parameters
13)
E.g. SARTORIUS
Interface Converter Type
15)
YDI05-Z
: Alternative connection
SIWXS...-3-..-..., SIWXS...-3-V...,
ISX...-..-..., ISX...-V...
2)
Power
3)
2)
Power
3)
2)
Data
3)
Sheet of
