Installation and Operation Guide
ED-DT318B
Drive Train Systems with Traction Control, Inverter/Controller, and Motor with 2 Speed Transmission

1 Introduction

Thank you for your purchase of a Danfoss Power Solutions™ PowerPhase
Controller package. Notify Danfoss Power Solutions immediately if any damage has occurred during shipment.
PLEASE READ THIS ENTIRE MANUAL BEFORE APPLYING VOLTAGE TO THE SYSTEM.
This manual applies to any Drivetrain found in

Table 1.1: ED-DT318B systems

Editron Product Model
ED-DT / EDITRON SUB SOLUTIONS (Electric drivetrain system with transmission)
ED-DT318B-PT2370E-360
ED-DT318B-PT3050-600
ED-DT318B-PT3050E-600
This state-of-the-art system is specifically designed for high performance drive applications. The shipped
package consists of 2 parts:
•
A high performance, liquid cooled, Brushless Permanent Magnet (PM) motor attached to a two speed
pneumatically controlled transmission and a system level control processor referenced in this manual as
the Transmission Control Unit or TCU.
•
A high-power, liquid-cooled inverter with a full-featured digital signal processor (DSP) controller
referenced in this manual as the Motor Control Unit (MCU), the controller or the inverter depending on
the functionality being discussed.
This manual covers installation and operation of the PowerPhase
powerful, lightweight, rugged, reliable, and designed based upon Danfoss Power Solutions' years of experience
developing and manufacturing motors and controllers for electric drive systems.
This manual also provides an overview of the CAN interface of a Danfoss Power Solutions Motor Control Unit
(MCU) coupled to an Eaton 2 speed transmission with a Transmission Control Unit (TCU). It includes details of the
CAN message layout and addressing schemes for command, feedback, and status messages.
The system provides many features required to develop a customized, high performance drive application. The
system is capable of fully regenerative, four-quadrant, bi-directional torque-controlled operation.
The PowerPhase DT2 system has been validated as a propulsion system. For applications other than propulsion
®
systems, please contact Danfoss Power Solutions to determine if the PowerPhase
operation in your desired application.
This guide gives a broad description of the motor, transmission, and controller package. We highly recommend
that you read through these instructions to familiarize yourself with the operation and installation of the
package before you begin installation. Please feel free to contact Danfoss Power Solutions if you have any
questions regarding installation, application, or service.
