Installation and Operation Guide
ED-DT318B
Drive Train Systems with Traction Control, Inverter/Controller, and Motor with 2 Speed Transmission
Dangerous voltages, currents, and energy levels exist in this product. Exercise extreme
DANGER
caution in the application of this equipment. Only qualified individuals should attempt
to install, set-up, and operate this equipment.
Incorrect motor and controller wiring can cause catastrophic failure. Proper connection
DANGER
of motor cables, signal cable, and DC cable are necessary for safe operation. Do not
swap motor windings to reverse direction.

1.1 About this Guide

This installation guide provides instructions and guidelines for mounting, starting, testing, and operating your
PowerPhase DT2 system. These instructions are intended for an experienced audience with a high level of
®
relevant knowledge.
This manual utilizes textual explanations, diagrams, photographs, computer-aided design (CAD) renderings, and
interface control drawings (ICDs) to guide the user through installation and operation. The latest ICD drawings
for the PowerPhase DT2 system are available by contacting Danfoss Power Solutions.
®
This manual is organized as follows: (1)
•
Section 1 is a general introduction to the PowerPhase® DT2 system
• Section 2 covers installation of the PowerPhase® DT2 system
•
Section 3 covers electrical connections
•
Section 4 covers cooling requirements for the motor and the inverter
•
Section 5 discusses vehicle operation considerations
•
Section 6 describes the hardware and protocols involved in system communications
•
Section 7 contains the definitions of the CANbus message between the VCU and the TCU
•
Section 8 describes the diagnostic software used to monitor the MCU
•
Section 9 describes vibration test results
•
Section 10 contains suggested response to status/error conditions.
•
Section 11 contains a glossary of terms used in this document.
•
Section 12 repeats all the safety notices contained within this document

1.1.1 Conventions

The inverter/controller/Motor Control Unit assembly may be referred to as the 'controller', the 'inverter' or
the 'MCU' depending on the specific functionality being discussed.
You, the customer and reader of this manual, are referred to as 'the user.'
The Signal Cable (Cable E in
Clickable links to other sections in the manual, such as figures or appendices, are red.
BC353060341319en-000101
Figure 1.1) may be referred to as motor position or temperature cable.
Revision D
Classified as Business
© Danfoss | November 2020 | 9
