Installation and Operation Guide
ED-DT318B
Drive Train Systems with Traction Control, Inverter/Controller, and Motor with 2 Speed Transmission
Pin Assignment
FEPS
Vbatt (TCU)
Note: The terminals and wires seals will be packaged in 3 different bags corresponding to the different wire
sizes as defined.
BC353060341319en-000101
Kit
Terminal
98010-021
15010-093
98010-020
15010-083
Revision D
Classified as Business
Wire Seal
Wire
16040-025
18 AWG
16040-019
14 AWG
Pin #
Signal Source
15
TCU Programing
16
Vehicle Battery
© Danfoss | November 2020 | 40
