AIN1A 11 Stereo Analog Input 1 (Input) - The full-scale level is specified in the Analog Characteristics specifica-
AIN1B 12 tion table.
AGND 13 Analog Ground (Input) - Ground reference for the internal analog section.
VA 14 Analog Power (Input) - Positive power for the internal analog section.
AFILTA 15 Anti-alias Filter Connection (Output) - Antialias filter connection for the channel A ADC input.
AFILTB 16 Anti-alias Filter Connection (Output) - Antialias filter connection for the channel B ADC input.
17
VQ Quiescent Voltage (Output) - Filter connection for the internal quiescent reference voltage.
18
FILT+ 19 Positive Voltage Reference (Output) - Positive reference voltage for the internal sampling circuits.
No Connect - This pin is not connected internally and should be tied to ground to minimize any poten-
NC 20
tial coupling effects.
AIN4A/MICIN1 21 Stereo Analog Input 4 / Microphone Input 1 & 2 (Input) - The full-scale level is specified in the Ana-
AIN4B/MICIN2 22 log Characteristics specification table.
AIN5A 23 Stereo Analog Input 5 (Input) - The full-scale level is specified in the Analog Characteristics specifica-
AIN5B 24 tion table.
Microphone Bias Supply (Output) - Low-noise bias supply for external microphone. Electrical charac-
MICBIAS 25
teristics are specified in the DC Electrical Characteristics specification table.
AIN6A 26 Stereo Analog Input 6 (Input) - The full-scale level is specified in the Analog Characteristics specifica-
AIN6B 27 tion table.
PGA Analog Audio Output (Output) - Either an analog output from the PGA block or high impedance.
PGAOUTA 28
PGAOUTB 29 See
30 No Connect - These pins are not connected internally and should be tied to ground to minimize any
NC
31 potential coupling effects.
AGND 32 Analog Ground (Input) - Ground reference for the internal analog section.
33
No Connect - These pins are not connected internally and should be tied to ground to minimize any
NC 34
potential coupling effects.
35
Serial Audio Interface Power (Input) - Determines the required signal level for the serial audio inter-
VLS 36
face. Refer to the Recommended Operating Conditions for appropriate voltages.
37
38 No Connect - These pins are not connected internally and should be tied to ground to minimize any
NC
39 potential coupling effects.
40
SDOUT 41 Serial Audio Data Output (Output) - Output for two's complement serial audio data.
SCLK 42 Serial Clock (Input/Output) - Serial clock for the serial audio interface.
Left Right Clock (Input/Output) - Determines which channel, Left or Right, is currently active on the
LRCK 43
serial audio data line.
MCLK 44 Master Clock (Input) - Clock source for the ADC's delta-sigma modulators.
DGND 45 Digital Ground (Input) - Ground reference for the internal digital section.
VD 46 Digital Power (Input) - Positive power for the internal digital section.
INT 47 Interrupt (Output) - Indicates an interrupt condition has occurred.
OVFL 48 Overflow (Output) - Indicates an ADC overflow condition is present.
6
"PGAOut Source Select (Bit 6)" on page 30.
