7. REGISTER DESCRIPTION

7.1

Chip ID - Register 01h

7 6
PART3 PART2
Function:
This register is Read-Only. Bits 7 through 4 are the part number ID, which is 1100b, and the remaining bits
(3 through 0) indicate the device revision as shown in
7.2

Power Control - Address 02h

7 6
Freeze Reserved
7.2.1

Freeze (Bit 7)

Function:
This function allows modifications to be made to certain control port bits without the changes taking effect
until the Freeze bit is disabled. To make multiple changes to these bits take effect simultaneously, set the
Freeze bit, make all changes, then clear the Freeze bit. The bits affected by the Freeze function are listed
in Table 5.
7.2.2

Power-Down MIC (Bit 3)

Function:
The microphone preamplifier block will enter a low-power state whenever this bit is set.
7.2.3

Power-Down ADC (Bit 2)

Function:
The ADC pair will remain in a reset state whenever this bit is set.
7.2.4

Power-Down Device (Bit 0)

Function:
The device will enter a low-power state whenever this bit is set. The power-down bit is set by default and
must be cleared before normal operation can occur. The contents of the control registers are retained
when the device is in power-down.
28
5 4
PART1 PART0
REV[3:0]
0000

Table 4. Device Revision

5 4
Reserved Reserved
Name
Mute
Gain[5:0]
Gain[5:0]

Table 5. Freeze-able Bits

3 2
REV3 REV2
Table 4 below.
Revision
A1
3 2
PDN_MIC PDN_ADC
Register Bit(s)
04h
07h
08h
1
REV1
1
Reserved
2
5:0
5:0
CS5346
0
REV0
0
PDN
DS861PP3
