12.ORDERING INFORMATION

Product Description
24-bit, 192 kHz
CS5346
Stereo Audio ADC
CDB5346 CS5346 Evaluation Board

13.REVISION HISTORY

Release
-Updated Title
-Added text to
-Added V/V representations for PGA and MIC gain specifications
PP1
-Updated Automotive THD+N and DNR limits
-Added reference to CDB5346 in
-Added note 3 and note for AFILTA/AFILTB capacitors in
PP2
-Removed references to automotive grade parts.
PP3
Contacting Cirrus Logic Support
For all product questions and inquiries, contact a Cirrus Logic Sales Representative.
To find the one nearest you, go to
