Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
The CHRYSLER firmware for DBALL2 is an all-in-one door lock and override module compatible with
specific Chrysler, Dodge, Jeep and Volkswagen vehicles. This guide supports the installation of a
DBALL2 in Remote Start Ready (RSR) mode with or without a Plug & Play (CHTHD1/THCHD1 or
CHTHD2/THCHD2)
T-Harness (optional). This solution offers three (3) configuration options to control your system: 3x
OEM Lock Remote Start Activation, RF System or SmartStart (all sold separately).
This module can only be flashed and configured using DirectLink at www.directechs.com or using
the Directechs Mobile application for smartphones. Refer to the Module Programming section on
pages 17-19 for more information.
Remote Start Ready (RSR) is a function that enables the interface module to remote start the vehicle
completely on its own. Consequently, there is no need for an aftermarket or an OEM remote starter in order to
start the vehicle from a distance.
Important!
This product is NOT compatible with vehicles equipped with a manual transmission.
Index
Vehicle Application Guide......................................................................................................................................................................
Installation
Type 1a (with CHTHD1/THCHD1 T-Harness).....................................................................................................................................
Type 1b (without T-Harness)...............................................................................................................................................................
Parking Light Vehicle Wiring Reference Chart (Type 1)........................................................................................................................
Type 2a (with CHTHD1/THCHD1 T-Harness).....................................................................................................................................
Type 2b (without T-Harness)...............................................................................................................................................................
Vehicle Wiring Reference Chart (Type 2).............................................................................................................................................
Type 3a (with CHTHD2/THCHD2 T-Harness R9)...............................................................................................................................
Type 3b (with CHTHD2/THCHD2 T-Harness R1-R6)..........................................................................................................................
Type 3c (without T-Harness)................................................................................................................................................................
Vehicle Wiring Reference Chart (Type 3)..............................................................................................................................................
Type 4 (not compatible with T-Harness)................................................................................................................................................
Vehicle Wiring Reference Chart (Type 4)..............................................................................................................................................
SmartStart/XL202 Installation Notes.....................................................................................................................................................
Programming
Module Programming for Installation (with Factory Keyless)...............................................................................................................
Module Programming for Installation (without Factory Keyless)..........................................................................................................
Module Reset........................................................................................................................................................................................
Hard Reset............................................................................................................................................................................................
Feature & Option List............................................................................................................................................................................
Feature Programming...........................................................................................................................................................................
LED Diagnostics & Troubleshooting.....................................................................................................................................................
....................................................................................................................................................
Limited One-Year Consumer Warranty..................................................................................................................................................
Quick Reference Guide.........................................................................................................................................................................
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Remote
Start Ready (RSR) mode without the use of a remote starter. See the Module Programming section for more
information.
® Chrysler, Dodge, Jeep and Volkswagen are registered trademarks and property of their respective companies.
Rev.: 20160908
02
03
04
05
06
07
08
09
10
11
12
14
15
16
17
19
20
20
21
22
23
24
25
26
© 2016 Directed. All rights reserved.
