Directed DBALL2 Installation Manual
  1. Manuals
  2. Brands
  3. Directed Manuals
  4. Remote Starter
  5. Xpresskit DBALL2
  6. Installation manual

Directed DBALL2 Installation Manual

Hide thumbs Also See for DBALL2:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Platform: DBALL2
Firmware:
NISS3HT Remote Start Ready
Update Alert: Firmware updates are posted
that you check for firmware and/or install guide updates prior to installing this product.

Installation Guide

The
NISS3H
T firmware for
specific Infiniti, and Nissan vehicles. This guide supports the installation of a
Ready (
RSR
) mode
with or without a Plug & Play
solution offers three (3) configuration options to control your system: 3x
Activation,
RF
System or SmartStart (all sold separately).
This module can only be flashed and configured using Xpress
Mobile application for smartphones. Refer to
completely on its own. Consequently, there is no need for an aftermarket or an
start the vehicle from a distance.
Important!
This product is
NOT

Index

Vehicle Application Guide .....................................................................................................................................................02
Installation
(Wiring Diagram & Vehicle Wiring Reference Chart )
Type 1 Wiring Diagram
with
Type 1 Wiring Diagram without T-Harness ...........................................................................................................................04
Type 2 Wiring Diagram without T-Harness ...........................................................................................................................08
SmartStart/XL202 Installation Notes.....................................................................................................................................10
Module Programming............................................................................................................................................................11
Module Reset........................................................................................................................................................................13
Hard
Reset
............................................................................................................................................................................13
Feature & Option List............................................................................................................................................................14
Feature Programming...........................................................................................................................................................14
LED Diagnostics & Troubleshooting .....................................................................................................................................15
Parking Light Error Codes ....................................................................................................................................................17
Limited One-Year Consumer
Quick Reference Guide ........................................................................................................................................................19

SmartStart Compatible

SmartStart is equipped with D2D which means it can be connected to an interface module and used in
Start Ready (
RSR
information.
® Infiniti and Nissan
are registered trademarks and property of
DBALL
2 is an all-in-one door lock and override module compatible with
THNISS3/THNISS3D
the Module Programming section
RSR
) is a function that enables the interface module to remote start the vehicle
compatible with vehicles equipped with a manual transmission.
s
T-Harness THNISS3/THNISS3D .............................................................................................03
Warranty
.................................................................................................................................18
,
) mode
without
the use of
their respective companies
(RSR)
Installation
on
the web on a regular basis. We recommend
DBALL
T-Harness ( ptional)
OEM
Lock Remote Start
VIP
at www.directechs.com or using the Directechs
s
a remote starter.
See the
.
2 in Remote Start
o
. This
on page
11
for more information.
OEM
remote starter in order to
Module Programming
section for more
© 2017 Directed. All rights reserved.
Rev.: 20170817
Remote

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBALL2 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed DBALL2

Summary of Contents for Directed DBALL2

  • Page 1: Installation Guide

    Remote Start Ready ( ) mode without the use of a remote starter. See the Module Programming section for more information. ® Infiniti and Nissan are registered trademarks and property of their respective companies © 2017 Directed. All rights reserved.
  • Page 2 SS: Integrated Security & Monitoring FOB: Sync CAN Interface w/ FOB Remote ST: Function/Feature Status PK: Transponder & Immobilizer Override [1] Special programming required (see Module Programming section). It is also NOT COMPATIBLE with the optional T-harness THNISS3/THNISS3D. © 2017 Directed. All rights reserved.
  • Page 3 THNISS NOT USED You can connect to B-02 B-01 either a RFTD OR a SmartStart module. Refer to the SmartStart/ Installation Notes for OBDII Brake Pedal Diagnostic 16-pin Connector more information. (connector side view) © 2017 Directed. All rights reserved.
  • Page 4 31 30 29 28 27 26 25 24 23 22 21 (-) Driver Door Trigger (RAP Off): pin 39 With the exception of the OBDII Diagno tic connector, all adapters are displayed from the wire side (unless specified otherwise). © 2017 Directed. All rights reserved.
  • Page 5 Driver Door Trigger Gray or Red BCM in passenger kick panel. Green Brake White Brake Switch. White HS CAN High Blue Data Diagnostic Conn (OBDII). White HS CAN Low Pink Data Diagnostic Conn (OBDII). White © 2017 Directed. All rights reserved.
  • Page 6 Driver Door Trigger Lt. Blue BCM behind instrument cluster. Green Brake Lt. Green or Red/Gre Brake Switch. White HS CAN High Blue Data Diagnostic Conn (OBDII). White HS CAN Low Pink Data Diagnostic Conn (OBDII). White © 2017 Directed. All rights reserved.
  • Page 7 Lt. Blue BCM behind instrument cluster. Green Brake Lt. Green 2 or 4 Brake Switch. White HS CAN High Blue Data Diagnostic Conn (OBDII). White HS CAN Low Pink Data Diagnostic Conn (OBDII) White © 2017 Directed. All rights reserved.
  • Page 8 (-) Driver Door Trigger (RAP Off): Violet, pin 7 [1] These wires are optional connections and are only required if features ‘OEM Security Disarm on Data’ & ‘Door Lock Control On Data’ are disabled. Feature & Option List section. © 2017 Directed. All rights reserved.
  • Page 9 BCM behind glove box. White Parking Lights Red/Blue Dimmer Switch. White HS CAN High Blue Data Diagnostic Conn (OBDII) Black HS CAN Low Pink Data Diagnostic Conn (OBDII) Black Circuit breaker behind Diagnostic Conn. White © 2017 Directed. All rights reserved.
  • Page 10 Combination Refer to the Passive Keyless Entry ( ) Installation Guide (N2102T) for detailed wiring information. & SmartStart Combination Refer to the Passive Keyless Entry ( ) Installation Guide (N2102T) for detailed wiring information. © 2017 Directed. All rights reserved.
  • Page 11 The will continue Insert key fob & to flash orange. into key port Flashes Go to the next page t complete the module programming. You have successfully completed the module programming sequence. © 2017 Directed. All rights reserved.
  • Page 12 START Cycle ignition OFF two times. STOP STOP brake pedal flashes green 3 seconds then goes off. & The module is now programmed. Flashes 3 seconds You have successfully completed the module programming sequence. © 2017 Directed. All rights reserved.
  • Page 13 Wait 3 seconds until the LED turns solid orange , and w 10 more seconds & until the LED starts to flash orange red. Solid Flashes & Release the programming button. The turns solid red. Release Solid © 2017 Directed. All rights reserved.
  • Page 14 2 seconds to confirm the end of the programming sequence. Press and HOLD the programming button for 3 seconds. After 3 seconds, the will turn orange for 2 seconds to confirm the end of the programming sequence. © 2017 Directed. All rights reserved.
  • Page 15 The Violet/Green or Violet/Brown wire did not detect the expected voltage value. Refer to "Installation (wiring Flashes red MUX not detected. diagrams & vehicle wiring reference charts)" to check the connections. © 2017 Directed. All rights reserved.
  • Page 16 Refer to feature when RFTD feature is disabled. programing section for more information. An RSR feature file mismatch was detected. Please Flashes red Feature error. contact Technical Support. © 2017 Directed. All rights reserved.
  • Page 17 Hood shutdown/Remote start safety override switch is ON*. Remote start safety override switch is ON*. * If the vehicle hood status is supported through data, it will also report a 7 flash safety override code. © 2017 Directed. All rights reserved.
  • Page 18 CLAIM OR DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER ’S...

  • Page 19: Quick Reference Guide

    Quick Reference Guide DBALL2-NISS3HT Remote Start Ready (RSR) Installation Vehicle Takeover with Get In and Go Pit Stop Mode Pit Stop Mode feature is practical when you need to stop and run an errand, Close the vehicle doors, hood and trunk, then press but wish to keep the engine running.
  • Page 20 Quick Reference Guide DBALL2-NISS3HT Remote Start Ready (RSR) Installation Remote Start Ready ( List of Available Commands Remote Start Ready ( ) is a function that enables the interface Note that the information below is for Viper, Clifford and Python models. Icons and module to remote start the vehicle completely on its own.
  • Page 21 Now you can remote start, lock and unlock your car just by pushing a button on your smartphone; using the SmartStart App from Directed, the leader in vehicle security and remote start. The simple graphical interface gives you control over the following features of your installed remote start or security with remote start system: Ÿ...
