Platform: DBALL/DBALL2
Firmware: GM9 Remote Start Ready (RSR) Installation
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
This guide supports the installation of a DBALL in Remote Start Ready (RSR) mode. This solution offers
three (3) configuration options to control your system; 3x OEM Lock Remote Start Activation,
XpressStart Kit or SmartStart (all sold separately).
Remote Start Ready (RSR) is a function that enables the interface module to remote start the vehicle
completely on its own. Consequently, there is no need for an aftermarket or an OEM remote starter in order to
start the vehicle from a distance.
Important!
This product is NOT compatible with vehicles equipped with a manual transmission.
Index
Vehicle Application Guide...................................................................................................................................................
Key2GO & 1KEY.................................................................................................................................................................
Type 1.................................................................................................................................................................................
Type 1 - Vehicle Wiring Reference Chart...........................................................................................................................
Type 2.................................................................................................................................................................................
Type 2 - Vehicle Wiring Reference Chart...........................................................................................................................
SmartStart/XL202 Installation Notes..................................................................................................................................
Programming
Module Programming.........................................................................................................................................................
Keyport Location.................................................................................................................................................................
Module Reset.....................................................................................................................................................................
Hard Reset.........................................................................................................................................................................
Feature & Option List..........................................................................................................................................................
Feature Programming.........................................................................................................................................................
LED Diagnostics & Troubleshooting...................................................................................................................................
Parking Light Error Codes..................................................................................................................................................
Limited One-Year Consumer Warranty...............................................................................................................................
Quick Reference Guide......................................................................................................................................................
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Remote
Start Ready (RSR) mode without the use of a remote starter. See the Module Programming section for more
information.
® Buick, Cadillac, and Chevrolet are registered trademarks and property of their respective companies.
Rev.: 20140916
02
03
04
05
08
09
10
11
13
14
14
15
16
17
18
19
20
© 2014 Directed. All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Directed DBALL
Summary of Contents for Directed DBALL
-
Page 1: Table Of Contents
Installation Guide This guide supports the installation of a DBALL in Remote Start Ready (RSR) mode. This solution offers three (3) configuration options to control your system; 3x OEM Lock Remote Start Activation, XpressStart Kit or SmartStart (all sold separately). -
Page 2: Vehicle Application Guide
• • • • Legend: PK: Transponder & Immobilizer Override DL: OE Door Lock & Alarm Controls EIPS: Engine Idle Protection System RS: Engine Start & Status SS: Entry Point Status-Security ST: Function/Feature Status © 2014 Directed. All rights reserved. -
Page 3: Key2Go & 1Key
Any first-time user must re-register to gain access to Key2GO, and some additional information will be required to complete the registration process, such as your Directed account number and store name. Key2GO is compatible with XpressVIP 4.5 or higher and requires an XKLoader. -
Page 4: Installation Type 1
This connection is only required when the EIPS (Engine Idle Protection System) feature is activated. With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise). © 2014 Directed. All rights reserved. -
Page 5: Type 1 - Vehicle Wiring Reference Chart
22 Negative BCM under driver dash White 26 Pin Horn Brown/White 19 Negative BCM under driver dash Brown 26 Pin Red/White or Red/Brown (+) 12V 4 Positive BCM under driver dash Blue 27 pin © 2014 Directed. All rights reserved. - Page 6 BCM in center console passenger side White 26 Pin Horn Brown/White 19 Negative BCM in center console passenger side Brown 26 Pin Red/Gray (+) 12V 4 Positive BCM in center console passenger side Blue 27 Pin © 2014 Directed. All rights reserved.
- Page 7 Parking Lights Gray 22 Negative BCM under driver dash White 26 Pin Horn Brown/White 19 Negative BCM under driver dash Brown 26 Pin Red/Violet (+) 12V 4 Positive BCM under driver dash Blue 27 Pin © 2014 Directed. All rights reserved.
-
Page 8: Type 2
This connection is only required when the EIPS (Engine Idle Protection System) feature is activated. With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise). © 2014 Directed. All rights reserved. -
Page 9: Type 2 - Vehicle Wiring Reference Chart
Green/Gray 22 Negative BCM under driver dash White 26 Pin 2015 Horn Brown/White 19 Negative BCM under driver dash Brown 26 Pin Red/Violet (+) 12V 4 Positive BCM under driver dash Blue 27 pin © 2014 Directed. All rights reserved. -
Page 10: Smartstart/Xl202 Installation Notes
Button 1. Use the D2D Crossover (XOVER) cable that is provided with XL202, and NOT the one in the DBALL package. 2. The modules must be connected in a specific order. Refer to the Module Programming section for more information. -
Page 11: Module Programming
Note: Before connecting either the XL202 or SmartStart module to DBALL, it is important to ensure that the proper feature and function programming is selected using XpressVIP (version 4.5 or higher). Visit www.xpresskit.com to download the latest version of the application. - Page 12 Click on Submit Key2GO Request. Once the configuration is completed, r econnect the module. & The LED turns ON solid green for 3 seconds, then turns off. Solid x3 Secs You have successfully completed the module programming sequence. © 2014 Directed. All rights reserved.
-
Page 13: Keyport Location
Open the center console and place the transmitter in the transmitter pocket GMC Yukon 2015 with the buttons facing the front of the vehicle. A, G H, J © 2014 Directed. All rights reserved. -
Page 14: Module Reset
Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds & until the LED starts to flash orange and red. Solid Flashes & Release the programming button. The LED turns ON solid red. Release Solid © 2014 Directed. All rights reserved. -
Page 15: Feature & Option List
Locks all doors w hen the vehicle is moving. Unlocks all doors w hen ignition turns OFF. The OEM alarm w ill not be controlled by DBALL upon remote start. No disarm or arm command w ill be 1. Disabled executed at the beginning or end of the sequence;... -
Page 16: Feature Programming
Press the lock/arm or unlock/disarm button on aftermarket transmitter to change the option of the selected feature. When installing the DBALL in RSR using 3x OEM Lock Remote Start Activation only, there is no aftermarket transmitter on which to press lock/unlock to change the options of the selected feature. -
Page 17: Led Diagnostics & Troubleshooting
Otherwise, the start signal was not received by the Flashes Flashes green green START ON command received. module. In a W2W install, it will show only if the ignition quickly quickly input wire is used. © 2014 Directed. All rights reserved. -
Page 18: Parking Light Error Codes
Brake shutdown. Hood shutdown/Remote start safety override switch is ON*. Remote start safety override switch is ON*. * If the vehicle hood status is supported through data, safety override switch input will report 7 flashes. © 2014 Directed. All rights reserved. -
Page 19: Limited One-Year Consumer Warranty
Part was purchased from an authorized DIRECTED dealer; and the Part is returned to DIRECTED, postage prepaid, along with a clear, legible copy of the receipt or bill of sale bearing the following information: consumer’s name, address, telephone number, the authorized licensed dealer’s name and complete... -
Page 20: Quick Reference Guide
Quick Reference Guide DBALL/DBALL2-GM9 Remote Start Ready (RSR) Installation Vehicle Takeover with Get In and Go* Pit Stop Mode The Pit Stop Mode feature is practical when you need to stop and run an errand, Close the vehicle doors, hood and trunk, then press but wish to keep the engine running. -
Page 21: Smartstart Compatible
3.0 enables a "Cloud-Connected Car" like never before, providing an entirely new the trunk release (optional). level of 2-way interaction with your vehicle. Connectivity is managed through the Directed Cloud Services (DCS) network linking car, app, end user, and the Internet. Press once, then... - Page 22 (i.e. 1 to 5 minutes) without detecting Remote start the vehicle. Ÿ the fob, DBALL will send a signal to the vehicle in order to shut off the engine. Turn the engine off. Ÿ...
