Platform: DBALL/DBALL2
Firmware: FORD5 Remote Start Ready (RSR) Installation
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
This guide supports the installation of a DBALL in Remote Start Ready (RSR) mode. This solution
offers three (3) configuration options to control your system: 3x OEM Lock Remote Start Activation, RF
Kit or SmartStart (all sold separately).
Remote Start Ready (RSR) is a function that enables the interface module to remote start
the vehicle completely on its own. Consequently, there is no need for an aftermarket or an
OEM remote starter in order to start the vehicle from a distance.
Important!
This product is NOT compatible with vehicles equipped with a manual transmission.
Index
Vehicle Application Guide...................................................................................................................................................
Key2GO............................................................................................................................................................................
Installation Type 1...............................................................................................................................................................
Installation Type 2...............................................................................................................................................................
Installation Type 3...............................................................................................................................................................
SmartStart/XL202 Installation Notes..................................................................................................................................
Programming
Module Programming.........................................................................................................................................................
Module Reset.....................................................................................................................................................................
Hard Reset.........................................................................................................................................................................
Feature & Option List..........................................................................................................................................................
Feature Programming.........................................................................................................................................................
LED Diagnostics & Troubleshooting...................................................................................................................................
Parking Light Error Codes..................................................................................................................................................
Limited One-Year Consumer Warranty...............................................................................................................................
Quick Reference Guide......................................................................................................................................................
SmartStart Compatible
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Remote
Start Ready (RSR) mode without the use of a remote starter. See the Module Programming section for more
information.
® Ford is a registered trademark and property of the Ford Motor Company.
Rev.: 20160317
02
02
03
05
07
09
10
12
12
13
13
14
15
16
17
© 2016 Directed. All rights reserved.
Advertisement
Table of Contents
Related Manuals for Directed Xpresskit DBALL
Summary of Contents for Directed Xpresskit DBALL
-
Page 1: Table Of Contents
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Remote Start Ready (RSR) mode without the use of a remote starter. See the Module Programming section for more information. ® Ford is a registered trademark and property of the Ford Motor Company. © 2016 Directed. All rights reserved. -
Page 2: Vehicle Application Guide
Any first-time user must re-register to gain access to Key2GO, and some additional information will be required to complete the registration process, such as your Directed account number and store name. Key2GO requires an XKLoader. -
Page 3: Installation (Wiring Diagram & Vehicle Wiring Reference Chart) Installation Type 1
RFTD OR a SmartStart module. Refer to the SmartStart/XL202 Installation Notes for more information. Not required in D2D mode. With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise). © 2016 Directed. All rights reserved. - Page 4 C2280A Connector, located at BCM Green Data TX Yellow/Orange 54 Data C2280C Connector, located at BCM Blue Data RX Violet/Gray Data C2280C Connector, located at BCM Blue Push-To-Start C2280C Connector, located at BCM Blue Locating Components © 2016 Directed. All rights reserved.
-
Page 5: Installation Type 2
RFTD OR a SmartStart module. Refer to the SmartStart/XL202 Installation Notes for more information. Not required in D2D mode. With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise). © 2016 Directed. All rights reserved. - Page 6 C2280A Connector, located at BCM White Data TX Yellow/Orange Data C2280C Connector, located at BCM Blue Data RX Violet/Gray Data C2280C Connector, located at BCM Blue Push-To-Start Brown/Violet C2280C Connector, located at BCM Blue Locating Components © 2016 Directed. All rights reserved.
-
Page 7: Installation Type 3
Refer to the SmartStart/XL202 (+) PTS: Installation Notes for more information. pin 28 Not required in D2D mode. With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise). © 2016 Directed. All rights reserved. - Page 8 C2280A Connector, located at BCM White Data TX Yellow/Orange Data C2280C Connector, located at BCM Blue Data RX Violet/Gray Data C2280C Connector, located at BCM Blue Push-To-Start C2280C Connector, located at BCM Blue Locating Components © 2016 Directed. All rights reserved.
-
Page 9: Smartstart/Xl202 Installation Notes
Refer to the Passive Keyless Entry (PKE) Installation Guide (N2102T) for detailed wiring information. RF Kit, PKE & SmartStart BT Combination Refer to the Passive Keyless Entry (PKE) Installation Guide (N2102T) for detailed wiring information. © 2016 Directed. All rights reserved. -
Page 10: Module Programming
Press the Push-To-Start (PTS) button to turn the ignition ON. & ENGINE PUSH 1X START The LED flashes green. STOP Flashes Green Go to the next page to complete the module programming. © 2016 Directed. All rights reserved. - Page 11 & The LED turns ON solid green for 3 seconds, then turns off. Solid x3 Secs Remove You may now reinstall the key fob battery. Battery You have successfully completed the module programming sequence. © 2016 Directed. All rights reserved.
-
Page 12: Module Reset
Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds & until the LED starts to flash orange and red. Solid Flashes & Release the programming button. The LED turns ON solid red. Release Solid © 2016 Directed. All rights reserved. -
Page 13: Feature & Option List
No activity for 30 seconds; after 30 seconds, the LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. Press and HOLD the programming button for 3 seconds. After 3 seconds, the LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. © 2016 Directed. All rights reserved. -
Page 14: Led Diagnostics & Troubleshooting
RSR Code 3x OEM Lock Remote Start Activated from W eb automatically when using RSR flash tool or can be Flashes Activation was attempted when red x7 done manually. RFTD feature is disabled. © 2016 Directed. All rights reserved. -
Page 15: Parking Light Error Codes
Brake shutdown. Hood shutdown/Remote start safety override switch is ON*. Remote start safety override switch is ON*. * If the vehicle hood status is supported through data, safety override switch input will report 7 flashes. © 2016 Directed. All rights reserved. -
Page 16: Limited One-Year Consumer Warranty
Part was purchased from an authorized DIRECTED dealer; and the Part is returned to DIRECTED, postage prepaid, along with a clear, legible copy of the receipt or bill of sale bearing the following information: consumer’s name, address, telephone number, the authorized licensed dealer’s name and complete... -
Page 17: Quick Reference Guide
This unique feature monitors a variety of parameters such as the key fob, vehicle * If the vehicle hood status is supported through data, it will also report a 7 flash speed sensor and door sensor, in order to perform takeover securily. safety override code. © 2016 Directed. All rights reserved. - Page 18 3 times, then to activate x3 + the panic mode. Press once, then to reset the x1 + remote starter runtime. * This output is configurable. see your authorized installation center for more information. © 2016 Directed. All rights reserved.
- Page 19 3.0 enables a "Cloud-Connected Car" like never before, providing an entirely new level of 2-way interaction with your vehicle. Connectivity is managed through the Directed Cloud Services (DCS) network linking car, app, end user, and the Internet. For more information, visit www.mysmartstart.com.
