Project Timber Evolution My Den Building Instructions page 3

Side Opening Window (LEFT)
position option
Left Side
Floor Plan
1220mm 1220mm
Side
Window
Opening
position
(LEFT)
610mm
610mm
Front of Building
1220mm
Side Window
Opening Panel
(LEFT)
Diagram
ID: PT25521
Door and Front Windows position options
Front
Door
Position
RIGHT
IMPORTANT: Always check the internal lining corner gap of the panels
Glazing Units
(610mm)
Single Door Panel
(LEFT)
Door Position (LEFT)
Top
Panel
Bottom
Panel
Single Door Panel
Door Position (RIGHT)
Top
Panel
Bottom
Panel
Glazing Units
(610mm)
(RIGHT)
