Project Timber Evolution My Den Building Instructions page 13

Right Gable (Low) Panel Stages
31
Side
(RIGHT)
Position and fix the side
Plain Gable Panel (right)
Door
(LEFT)
RIGHT - Wall Panels Section Stages
32
RIGHT - Gable Cloaking Strip (CS)
ID: PT25535
50mm
Back
Screws
Pilot drill holes
before fixing
Door on the Left Panel Stages
(RIGHT)
Front
ID: PT21077
50mm
Screws
Pilot drill holes
before fixing
Position and fix
Side
the right gable
(RIGHT)
cloaking strip
Parts List required:
1. Window Glazing Unit (W610mm) - (2) [ID: PT18490]
2. Plain Panel TOP (W1220mm) - (1) [ID: PT20323]
3. Plain Panel BOTTOM (W1220mm) - (1) [ID: PT25548]
Side
33
Side Opening Window (RIGHT) fixing
Front
ID: PT25522
50mm
Screws
Pilot drill holes
before fixing
Side
(RIGHT)
Position and fix the side
Window Panel (RIGHT)
Panel Position Diagram
Rear
Side
Side
(Left)
(Right)
Front of Building
