Project Timber Evolution My Den Building Instructions page 16

46
REAR - Roof Stand-Off Frame (SOF)
ID: PT21077
Position and fix
the Rear Frame.
44mm x 27mm
(1)
x 2475mm
50mm
Screws
Pilot drill holes
Back
before fixing
49 Drip Edge Flashing position
Back
Drip Edge
Flashing
47
GABLE - Roof Stand-Off Frame (SOF)
Position and fix
the Gable Frame
44mm x 27mm
(2)
x 2590mm
Front
Side
50
Drip Edge Flashing Length Size
Side
Building size
Gable
8x8
Frame
ID: PT21077
Side
Back
50mm
Pilot drill holes
Screws
before fixing
Back View
Drip Edge Flashing Lengths
L2530mm x 1
Drip Edge Flashing Stages
48
ID: 21173
Position and fix the
Drip Edge Flashing
50mm
Screws
Pilot drill holes
before fixing
Back
