My Den - Metal Roof
Building Instructions
Please read the instruction carefully
and retain for future reference
10x6
Cover Size:
10x6 My Den - Metal Roof
Side Opening Window (RIGHT)
Building shown
For Queries and Help please contact 01777 802300
Please note that all images are for illustration purpose only.
V1.4 20.04.22 INS0138
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Project Timber My Den Metal Roof
Summary of Contents for Project Timber My Den Metal Roof
- Page 1 My Den - Metal Roof Building Instructions Please read the instruction carefully and retain for future reference 10x6 Cover Size: 10x6 My Den - Metal Roof Side Opening Window (RIGHT) Building shown For Queries and Help please contact 01777 802300 Please note that all images are for illustration purpose only.
- Page 2 10x6 My Den - Metal Roof Side Window Opening (RIGHT) shown Metal Roof Floor Assembly position 610mm 1000mm 585mm x 1467mm (2) 505mm 1467mm x 1217mm (2) Back Panels Front Panels 10x6 Floor Plan position position 1220mm 610mm 610mm 1220mm 1220mm 585mm 1220mm...
- Page 3 Door and Front Windows position options Side Opening Window (LEFT) Glazing Units position option (610mm) Panel Front Left Side Bottom Floor Plan Panel Single Door Panel 1220mm 585mm 1220mm (LEFT) Door Position (LEFT) Side Window Opening Glazing Units position (LEFT) (610mm) 610mm 610mm...
- Page 4 Building Parts: 10x6 Evolution My Den Building Parts Part ID Metal Roof PT25541 PT25542 10ft Back Water Roof Section PT25543 Roof Section 1000mm Width Deflector Flashing 1000mm Width PT25531 Roof Section Roof Section 505mm Width PT25532 610mm Width Barge Board Gable Frame PT20322 Flashing...
- Page 5 Base Module Woodkits Parts List required: 1. Base Module I - 1220mm x 1893mm (2) 2. Base Module J - 585mm x 1893mm (1) 3. Gable Bearers - 38mm x 1817mm (2) ID: PT25397 ID: PT25393 ID: PT25394 Gable Bearers Fixing Kit Base Module (For each end of the assebled base)
- Page 6 Base Module Stages Base Module fixing Base Module fixing Base Module fixing Side 70mm 70mm Back 70mm Back Screws Screws Screws Pilot drill holes before fixing Side Front Side Front Front Alternate sides to screw together ID: PT23597 Gable Bearers are fitted on each side of Position the gable bearers each side to Pilot drill holes fully assembled base.
- Page 7 Floor Section Stages Base Module fixing Floor Stages Floor Stages Plinth 70mm Screws Back Pilot drill holes before fixing Side ID: 15603 Front ID: 18685 Side Base Module Lay and fix the Plinth Position the plinth into the top of lengths together at Front assembled base module...
- Page 8 Floor Section Stages Floor Stages Floor Stages Back Side Back Front 50mm Screws Pilot drill holes before fixing Fix the Floors with Place the floor assembly screws in angled inside the plinth and Side position base module. Wall Panels Section Stages Parts List required: 1220mm 1220mm...
- Page 9 Wall Panels Section Stages Left Gable (High) Panel Stages Left Gable (High) Panel Stages Left Gable and Door Panel (LEFT) Position *Check the Side Opening Window (LEFT) position option floor plan for guidelines. Position and fix ID: PT25534 the plain gable panel (Left) 50mm Lining...
- Page 10 Wall Panels Section Stages UPVC Door fixing UPVC Door fixing LEFT - Gable Cloaking Strip (CS) Front ID: PT21075 50mm Screws Side Pilot drill holes (LEFT) Side before fixing (LEFT) ID: 19503 Front Position and fix 80mm the gable Position and fit the UPVC Door Fix and secure the UPVC Door Cloaking Strip is used to fix section to the door panel (LEFT)
- Page 11 REAR - Wall Panels Section Stages Parts List required: 1220mm 585mm 1220mm 1. LEFT Back Panel 1220mm (1) 2. RIGHT Back Panel Lining 1220mm (1) Flush Lining Flush Lining Flush 3. CENTRE Back Panel 585mm (1) 4. Rear Cloaking Strip (2) 60mmx16mmx2012mm Panel Position Diagram 16mm...
- Page 12 REAR - Wall Panels Section Stages Back Panel Stages Back Panel Stages REAR - Cloaking Strip (CS) ID: PT25543 ID: PT25542 Back 50mm ID: PT21075 50mm 50mm Back Screws Back Screws Screws Position and fix Position and fix in place Align and fix the second back Pilot drill holes...
- Page 13 RIGHT - Gable Wall Panels Stages Right Gable (Low) Panel Stages RIGHT - Gable Cloaking Strip (CS) Side Opening Window (RIGHT) fixing Front Pilot drill holes ID: PT21075 before fixing ID: PT25522 50mm 50mm Back 50mm Screws Screws Screws ID: PT25532 Pilot drill holes Side Side...
- Page 14 Door on the Left Panel Stages Bottom Panel Stages Glazing Unit fixing Bottom Panel Stages Front Secure the Bottom Panel *Check the Front Window ID: PT25547 Panels position option (LEFT or RIGHT). 50mm Screws Position and align the Glazing Unit Check the corner gap of panel Front...
- Page 15 Top Panel Stages Top Panel Stages Glazing Unit fixing Glazing Unit Fix and secure Check the corner fixing the Top Panel gap of panel 70mm ID: PT20322 Screws ID: PT18490 Front Front 50mm ID: PT20322 Screws Position the Top Pilot drill holes Panel to the top Pilot drill holes Front...
- Page 16 Window Frame Cloaking Strip (CS) REAR - Roof Stand-Off Frame (SOF) GABLE - Roof Stand-Off Frame (SOF) ID: PT21075 ID: PT21075 Position and fix the Rear Frame. 44mm x 27mm x 3060mm Side Back Front Side 50mm Screws Position and fix the Gable Frames Panel 50mm...
- Page 17 Roof Section Stages Parts List required: 1. Metal Roof Section L2285mm x W610mm - (1) [ID: 21193] 2. 115mm Metal Roof Screws Floor Plan Rear Side Side (Left) (Right) Side Front (RIGHT) Front of Building Roof Section Stages Roof Section Stages Roof Section Stages Roof sections Roof section...
- Page 18 Roof Section Stages Roof Section Stages Roof Section Stages Metal Roof Cross-Section Diagram Only 1 screw is required to hold the position of 115mm Metal the roof. Roof Screw Metal Roof ID: 21193 Wall Panels 115mm Metal Roof Screws Ensure the 115mm metal roof screws 115mm Metal Ensure the 115mm metal roof screws is align fix through to the wall panels...
- Page 19 Roof Section Stages Roof Section Stages Roof Section Stages Roof Section Stages 1m Wide ID: 21150 ID: 21150 505mm Back Wide 115mm Metal ID: 21158 115mm Metal Roof Screws Back Side Roof Screws * Use Step ladder when Side Repeat previous roof fixing the roof sections, (LEFT) section fixing stages...
- Page 20 Roof Section Stages Barge Board Flashing Stages Monopitch Ridge Flashing Stages Side Front ID: 21181 25mm Metal Roof Screws Front Position and fix the Monopitch Ridge Flashing to the front of roof sections. These are the same lenghts Side Back of water deflector flashing UPVC Single Door Glazing Unit fixing UPVC Single Door Glazing Unit fixing...
- Page 21 UPVC Single Door Glazing Unit fixing UPVC Single Door Glazing Unit fixing UPVC Door Frame and UPVC Beading UPVC Door Frame Front UPVC Beading Door Glazing Insert the rubber packing strip to the top to secure the ID: 19655 glazing unit. Add a Position the bottom UPVC couple of rubber beading to the bottom...
- Page 22 Silicone Sealant - optional Silicone Sealant - optional Silicone Selant - optional * Silicone sealant is not provided with the building. Repeat previous stage The window frames can also be sealed with Silicone sealant can be added around where silicone sealant silicone sealant around the edges where the the edges of the window frames is applied.
- Page 23 Internal Cover Trims Internal Cover Trims Side Window Architrave Detail Position and fit Window the D Mould strips frames to cover the join ID: 21081 between the Add the side and bottom Window window frame. battens window architrave using Secure the strips panel pins.
- Page 24 Internal Cover Trims Internal Cover Trims Internal Cover Trims ID: 21081 Fix the skirting boards Fix the cladding cover around the top and strips over the joins in bottom of the panels. the internal cladding Cut to lenght and fix boards with Panel in place with Panel Pins...
