Evolution My Den
Building Instructions
Please read the instruction carefully
and retain for future reference
16x8
Cover Size:
16x8 My Den
Double Doors - Metal Roof
Building shown
For Queries and Help please contact 01777 802300
Please note that all images are for illustration purpose only.
V1.2 22.04.22 INS0147

Advertisement

loading
Need help?

Need help?

Do you have a question about the Evolution My Den 16x8 and is the answer not in the manual?

Questions and answers

Related Manuals for Project Timber Evolution My Den 16x8

Summary of Contents for Project Timber Evolution My Den 16x8

  • Page 1 Evolution My Den Building Instructions Please read the instruction carefully and retain for future reference 16x8 Cover Size: 16x8 My Den Double Doors - Metal Roof Building shown For Queries and Help please contact 01777 802300 Please note that all images are for illustration purpose only. V1.2 22.04.22 INS0147...
  • Page 2 16x8 Evolution My Den Double Doors Metal Roof Metal Roof Floor Assembly shown 942mm position 1000mm 2394mm x 1217mm (4) Back Panels Front Panels 16x8 Floor Plan position position 317.5mm 317.5mm 1220mm 1220mm 1220mm 1220mm 1220mm 1220mm 610mm 610mm Double Doors 1220mm 1220mm...
  • Page 3 Building Parts: 16x8 Evolution My Den Building Parts Part ID Double Doors - Metal Roof PT25544 PT25545 Roof Section PT25537 Back Water 1000mm Width Deflector Flashing PT25533 Roof Section Roof Section 942mm Width PT25535 1000mm Width Gable Frame PT20323 Barge Board Standoff Flashing PT20327...
  • Page 4 Base Module Woodkits ID: 20931 Fixing Kit Parts List required: 1. Base Module A - 1220mm x 2528mm (4) ID: PT25385 ID: PT25398 2. Gable Bearers - 38mm x 2452mm (2) Gable Bearers Base Module (For each end of the assebled base) Base Module fixing Base Module fixing Base Module fixing...
  • Page 5 Base Module Stages Base Module fixing Base Module fixing Base Module fixing 70mm Side Screws Floor Boards Plinth Back Floor Joist Pilot drill holes before fixing Side of Side 70mm Front Base Module Screws Front ID: PT25398 Gable Bearers are fitted on each side of Position the gable bearers each side to fully assembled base.
  • Page 6 Floor Section Stages Floor Stages Floor Stages Floor Sections Diagram Plinth 70mm Screws Wall Floor 8ft Gable Boards Panel ID: 15768 16ft Plinth Plinth Front ID: 15769 ID: 15606 16ft Plinth 8ft Gable Back Plinth Floor Joist Plinth Pilot drill holes Base Module before fixing Base Module...
  • Page 7 Floor Section Stages Floor Stages Side Back Front Place the floor assembly inside the plinth and base module. Wall Panels Section Stages 1220mm 1220mm Parts List required: 1. Left Gable Panel - LOW (1) 2. Back Left - Plain Panel (1) Lining Flush Lining Flush 3.
  • Page 8 Wall Panels Section Stages LEFT Gable (Low) Panel Stage LEFT Gable (Low) Panel Stage Left Gable Low and Back (LEFT) Panel Position 50mm Position and fix 50mm ID: PT25544 the plain gable Screws Screws ID: PT25523 panel (Left) Side ID: PT25533 Pilot drill holes Front Pilot drill holes...
  • Page 9 Wall Panels Section Stages Side Opening Window (LEFT) fixing ID: PT25521 50mm Screws Front Side (LEFT) Position and fix in place the Window Side Gable (High) Panel REAR - Wall Panels Section Stages 1220mm 1220mm Parts List required: 1. Back Centre - Plain Panel (2) 2.
  • Page 10 REAR - Wall Panels Section Stages Back (CENTRE) Panel Stages Back Panels Position Back Cloaking Strip (CS) fixing ID: PT21082 Pilot drill holes Gap for guttering at top before fixing ID: PT25537 74mm 50mm Screws 50mm Pilot drill holes Screws before fixing Back Back...
  • Page 11 REAR - Wall Panels Section Stages Back (RIGHT) Panel Stages ID: PT25545 Back Position and fix 50mm Pilot drill holes the back panel Screws (RIGHT) before fixing RIGHT - Gable Panels Section Stages Cloaking Strip Right Opening 1220mm 1220mm Window (High) Right Gable Panel (Low) Panel...
  • Page 12 RIGHT - Gable Panels Section Stages Right Gable (Low) Panel Stages RIGHT - Gable Cloaking Strip (CS) Side Opening Window (RIGHT) fixing ID: PT25535 ID: PT25522 50mm 50mm Screws Position and fix Screws the right gable Pilot drill holes cloaking strip before fixing Back Pilot drill holes...
  • Page 13 Front Panels Section Stages Bottom Panel Stage Front Corner Panel Stage Front Corner Panel Stage ID: PT20327 ID: PT25540 50mm 50mm Screws Screws Pilot drill holes before fixing Check the corner gap of panel Front ID: PT25540 Side Rotate the panel so that the (Right) flush side is on the inside Pilot drill holes...
  • Page 14 Front Panels Section Stages Top Panel Stage Top Panel Stage Front Cloaking Strip (CS) fixing Front ID: PT20323 ID: PT21082 Position the 70mm Top Panel and Screws secure in place. 50mm Screws 50mm Pilot drill holes Screws before fixing Pilot drill holes before fixing Top Panel fixing Pilot drill holes...
  • Page 15 Front Panels (Double Door) Section Stages Double Door Panel fixing UPVC Double Door fixing Double Door Panel fixing Front ID: PT25539 ID: PT25539 50mm Screws Pilot drill holes before fixing Pilot drill holes before fixing Front ID: 19504 Position the Door Front Panel and secure Secure the Door Panel and the Glazing Unit.
  • Page 16 Front Panels (Double Doors) Section Stages Front Cloaking Strip (CS) fixing ID: PT21082 Front Pilot drill holes before fixing 50mm Position and fix the cut-to-size Front Cloaking Strip (CS) Screws Front Panels Section Stages 317.5mm 16mm Parts List required: Lining Flush 1.
  • Page 17 Front Panels Section Stages Glazing Unit fixing Glazing Unit fixing Bottom Panel Stage Front Front 50mm Screws ID: PT20327 ID: PT18490 Secure the Glazing Unit. Use 70mm ID: PT18490 Screws Secure the through the Glazing Unit. Front Pilot drill holes back rebate Use 70mm before fixing...
  • Page 18 Front Panels Section Stages Front Corner Panel Stage Front Corner Panel Stage Front Cloaking Strip (CS) fixing ID: PT21082 ID: PT25540 50mm 50mm Screws Screws Front Pilot drill holes Pilot drill holes before fixing Front before fixing Fix the cut-to-size Front Fix in place the Fix the Front Corner Panel and the Glazing Unit.
  • Page 19 Drip Edge Flashing Stages REAR - Roof Stand-Off Frame (SOF) GABLE - Roof Stand-Off Frame (SOF) ID: PT21082 ID: PT21082 Flashing overlap Back Side 50mm Position and fix Front the Rear Frame. Back Screws Back Side 44mm x 27mm Position and fix Position and fix the x 2460mm the Gable Frame...
  • Page 20 Roof Section Stages Parts List required: 1. Metal Roof Section L2920mm x W942mm - (1) [ID: 21145] 2. 115mm Metal Roof Screws Front Side (RIGHT) Roof Section Stages Roof Section Stages Roof Section Stages 13mm 115mm Metal Roof sections Roof section Roof Screws overhang position...
  • Page 21 Roof Section Stages Roof Section Stages Roof Section Stages Metal Roof Cross-Section Diagram 115mm Metal Roof Screws 115mm Metal Roof Screw ID: 21145 Metal Roof Wall Panels Ensure the 115mm metal roof screws 115mm Metal Ensure the 115mm metal roof screws is align fix through to the wall panels Roof Screws and fix through to the wall panels below.
  • Page 22 Roof Section Stages Roof Section Stages Roof Section Stages Roof Section Stages 1m Wide ID: 21140 ID: 21140 1m Wide 115mm Metal Roof Screws ID: 21140 115mm Metal Roof Screws Position the 1m wide roof section and slot it into the first roof section.
  • Page 23 Roof Section Stages Barge Board Flashing Stages Monopitch Ridge Flashing Stages L3115mm x 1 ID: PT21181 L2530mm x 1 ID: PT21166 Flashing overlap Side Front Position and fix the Monopitch Ridge Flashing to the front of roof sections. Side 25mm Metal These are the same lengths Back Roof Screws...
  • Page 24 uPVC Double Door Glazing Unit fixing uPVC Double Door Glazing Unit fixing uPVC Door Frame and UPVC Beading uPVC Door Frame Front uPVC Beading Window Glazing Insert the rubber packing strip to the top to secure the ID: 19504 glazing unit. Add a Position the bottom UPVC couple of rubber beading to the bottom...
  • Page 25 Silicone Sealant - optional Silicone Sealant - optional Silicone Sealant - optional * Silicone sealant * Silicone sealant is not provided with is not provided with the building. the building. The uPVC door frame can be sealed The window frames can also be sealed with Silicone sealant can be added around with silicone sealant where the silicone sealant around the edges where the...
  • Page 26 Insulation Kits fixing Top Window Architrave Detail Side Window Architrave Detail Top window Window architrave frames Window battens ID: 21092 Add the side and Side window bottom window architrave architrave using panel pins. Window Window frames battens See side window architrave detail.
  • Page 27 Insulation Kits fixing Insulation Kits fixing Insulation Kits fixing Fix the skirting boards around the top and bottom of the panels. ID: 21092 Cut to length and fix in place with Panel Pins ID: 21092 Fix the cladding cover strips over ID: 21092 Fit the edge frames around the joins in the internal cladding...
