Metal Roof Cross-Section Diagram
Metal
Roof
Ensure the 98mm metal roof screws
fix through to the wall panels
Side
(LEFT)
Roof Section Stages
55
Roof Section Stages
98mm Metal
98mm Metal
Roof Screws
Roof Screw
ID: 21149
Wall
Panels
Ensure the 98mm metal roof screws is align
and fix through to the wall panels below.
Roof Section Stages
Front
Parts List required:
1. Metal Roof Section L2920mm x W1000mm - (2) [ID: PT21140]
2. 98mm Metal Roof Screws
Side
(Left)
56
Roof Section Stages
Floor Plan
Rear
Side
(Right)
Front of Building
98mm Metal
Roof Screws
