Project Timber Evolution My Den Building Instructions page 10

23 UPVC Door fixing
Side
(LEFT)
Front
Position and fit the UPVC Door
section to the door panel (LEFT)
26 Left Gable (Low) Panel Stages
Side
(LEFT)
50mm
Position and fix the Side
Screws Gable (Low) Panel
Wall Panels Section Stages
24
Front
ID: 19503
80mm
Screws
ID: 19503
ID: PT25533
Front
Pilot drill holes
before fixing
UPVC Door fixing
Fix and secure the UPVC Door
section to the door panel
LEFT - Gable Cloaking Strip (CS)
25
Side
(LEFT)
Cloaking Strip is used to fix
the panels together
ID: PT21077
50mm
Screws
Pilot drill holes
before fixing
Position and fix
the gable
cloaking strip
