Evolution My Den
Building Instructions
Please read the instruction carefully
and retain for future reference
8x6
Cover Size:
8x6 My Den - Metal Roof
Side Opening Window (RIGHT)
Building shown
For Queries and Help please contact 01777 802300
Please note that all images are for illustration purpose only.
V1.4 20.04.22 INS0140
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Project Timber Evolution My Den 8x6
Summary of Contents for Project Timber Evolution My Den 8x6
- Page 1 Evolution My Den Building Instructions Please read the instruction carefully and retain for future reference Cover Size: 8x6 My Den - Metal Roof Side Opening Window (RIGHT) Building shown For Queries and Help please contact 01777 802300 Please note that all images are for illustration purpose only. V1.4 20.04.22 INS0140...
- Page 2 8x6 Evolution My Den Metal Roof Side Window Opening (RIGHT) Metal Roof Floor Assembly shown position 515mm 1000mm 585mm x 2348mm (1) 2348mm x 1217mm (1) Back Panels Front Panels 8x6 Floor Plan position position 1220mm 610mm 1220mm 1220mm 1220mm Single Door 610mm...
- Page 3 Door and Front Windows position options Side Opening Window (LEFT) Glazing Units position option (610mm) Panel Left Side Front Bottom Floor Plan Panel Single Door Panel (LEFT) 1220mm 1220mm Door Position (LEFT) Side Window Opening Glazing Units position (610mm) (LEFT) 610mm 610mm Door...
- Page 4 Building Parts: 8x6 Evolution My Den Metal Roof Building Parts Part ID 8ft Back Water PT25541 Roof Section Roof Section Deflector Flashing 1000mm Width PT25542 1000mm Width Roof Section Barge Board PT25531 515mm Width Flashing PT25532 Gable Frame Drip Edge Standoff Flashing PT20323...
- Page 5 Base Module Woodkits Parts List required: 1. Base Module I - 1893mm x 2440mm (2) 2. Gable Bearers - 38mm x 1817mm (2) ID: PT25397 ID: PT25393 Gable Bearers Base Module Fixing Kit (For each end of the assebled base) Base Module fixing Base Module fixing Base Module fixing...
- Page 6 Base Module Stages Base Module Diagram Base Module fixing Base Module fixing 70mm Side 70mm Back Floor Boards Plinth Screws Screws Floor Joist Pilot drill holes before fixing Side Side of Base Module Front Front ID: PT23597 Gable Bearers are fitted on each side of Position the gable bearers each side to fully assembled base.
- Page 7 Floor Section Stages Floor Stages Floor Stages Floor Sections Diagram Plinth 70mm Wall Floor Screws Boards Panel Back Pilot drill holes before fixing ID: 15906 Floor Joist ID: 18685 Plinth Front Side Base Module Base Module Lay and fix the Plinth Position the plinth into the top of lengths together at pre-assembled base module...
- Page 8 Floor Section Stages Floor Stages Back Front Side Place the floor assembly inside the plinth and base module. Wall Panels Section Stages Parts List required: 1220mm 1220mm 1. Door Panel - LEFT (1) 2. UPVC Single Door - LEFT (1) Lining Flush 3.
- Page 9 Wall Panels Section Stages Left Gable (High) Panel Stages Left Gable (High) Panel Stages Left Gable and Door Panel (LEFT) Position *Check the Side Opening Window (LEFT) position option floor plan for guidelines. 50mm Position and fix Screws the plain gable panel (Left) Lining ID: PT25534...
- Page 10 Wall Panels Section Stages UPVC Door fixing UPVC Door fixing LEFT - Gable Cloaking Strip (CS) Front ID: 19503 ID: PT21074 50mm Screws Side Pilot drill holes Side (LEFT) before fixing (LEFT) Front Position and fix 80mm the gable Position and fit the UPVC Door Fix and secure the UPVC Door Cloaking Strip is used to fix section to the door panel (LEFT)
- Page 11 REAR - Wall Panels Section Stages 1220mm 1220mm Parts List required: 1. LEFT Back Panel 1220mm (1) 2. RIGHT Back Panel Lining Flush Lining Flush 1220mm (1) 3. Rear Cloaking Strip (1) 60mmx16mmx2012mm Panel Position Diagram 16mm 16mm Rear 74mm 1146mm 1146mm 74mm...
- Page 12 REAR - Wall Panels Section Stages Back Panel Stages ID: PT25542 Back 50mm Position and fix the back panel Screws (RIGHT) and cloaking strip RIGHT - Gable Wall Panels Section Stages Cloaking Strip Parts List required: Right Opening 585mm 1220mm Window (High) Right Gable 1.
- Page 13 RIGHT - Gable Wall Panels Section Stages Right Gable (Low) Panel Stages Back Panel Stages RIGHT - Gable Cloaking Strip (CS) ID: PT25542 ID: PT21074 ID: PT25532 50mm 50mm Back Screws Screws Pilot drill holes Side Pilot drill holes before fixing Back before fixing (RIGHT)
- Page 14 Door on the Left Panel Stages Bottom Panel Stages Glazing Unit fixing Bottom Panel Stages Front ID: PT20327 Secure the Bottom Panel *Check the Front Window Panels position option (LEFT or RIGHT). 50mm Screws Position and align the Glazing Unit Check the corner gap of panel Front...
- Page 15 Top Panel Stages Top Panel Stages Top Panel Stages Check the corner Top Panel fixing Fix and secure gap of panel Front the Top Panel ID: PT20323 Front 50mm Front 70mm Screws Screws Position the Top Pilot drill holes Panel to the top Pilot drill holes before fixing of glazing units...
- Page 16 Drip Edge Flashing Stages REAR - Roof Stand-Off Frame (SOF) GABLE - Roof Stand-Off Frame (SOF) ID: PT21074 ID: PT21074 ID: 21173 Position and fix Position and fix the the Rear Frame. Drip Edge Flashing 44mm x 27mm Side Back Front Side x 2475mm...
- Page 17 Roof Section Stages Parts List required: 1. Metal Roof Section L2285mm x W515mm - (1) [ID: 21159] 2. 115mm Metal Roof Screws Floor Plan Rear Side Side Side (Left) (Right) Front (RIGHT) Front of Building Roof Section Stages Roof Section Stages Roof Section Stages Roof section Roof sections...
- Page 18 Roof Section Stages Roof Section Stages Roof Section Stages Metal Roof Cross-Section Diagram 115mm Metal Roof Screw Metal Roof ID: 21159 Wall Panels 115mm Metal Roof Screws Ensure the 98mm metal roof screws 115mm Metal Ensure the 115mm metal roof screws is align fix through to the wall panels Roof Screws and fix through to the wall panels below.
- Page 19 Roof Section Stages Roof Section Stages Roof Section Stages Roof Section Stages Only 1 screw is required Wide to hold the back in place in this stage Side ID: 21150 Front (LEFT) 115mm Metal ID: 21150 Roof Screws Roof section 115mm Metal position Roof Screws...
- Page 20 Roof Section Stages Barge Board Flashing Stages Monopitch Ridge Flashing Stages Side Front ID: 21166 25mm Metal Roof Screws Front Position and fix the Monopitch Ridge Flashing to the front of roof sections. Side These are the same lenghts Back of water deflector flashing UPVC Single Door Glazing Unit fixing UPVC Single Door Glazing Unit fixing...
- Page 21 UPVC Single Door Glazing Unit fixing UPVC Single Door Glazing Unit fixing UPVC Door Frame and UPVC Beading UPVC Door Frame Front UPVC Beading Door Glazing Insert the rubber packing strip to the top to secure the ID: 19655 glazing unit. Add a Position the bottom UPVC couple of rubber beading to the bottom...
- Page 22 Silicone Sealant - optional Silicone Sealant - optional Silicone Selant - optional * Silicone sealant is not provided with the building. Repeat previous stage The window frames can also be sealed with Silicone sealant can be added around where silicone sealant silicone sealant around the edges where the the edges of the window frames is applied.
- Page 23 Internal Cover Trims Internal Cover Trims Side Window Architrave Detail Position and fit Window the D Mould strips frames to cover the join ID: 21080 between the Add the side and bottom Window window frame. battens window architrave using Secure the strips panel pins.
- Page 24 Internal Cover Trims Internal Cover Trims Internal Cover Trims ID: 21080 Fix the skirting boards Fix the cladding cover around the top and strips over the joins in bottom of the panels. the internal cladding Cut to lenght and fix boards with Panel in place with Panel Pins...
