Evolution My Den
Building Instructions
Please read the instruction carefully
and retain for future reference
10x8
Cover Size:
10x8 My Den - Metal Roof
Side Opening Window (RIGHT)
Building shown
For Queries and Help please contact 01777 802300
Please note that all images are for illustration purpose only.
V1.4 20.04.22 INS0137
Advertisement
Related Manuals for Project Timber Evolution My Den
Summary of Contents for Project Timber Evolution My Den
- Page 1 Evolution My Den Building Instructions Please read the instruction carefully and retain for future reference 10x8 Cover Size: 10x8 My Den - Metal Roof Side Opening Window (RIGHT) Building shown For Queries and Help please contact 01777 802300 Please note that all images are for illustration purpose only.
- Page 2 10x8 Evolution My Den Metal Roof Side Window Opening (RIGHT) Metal Roof Floor Assembly shown position 610mm 1000mm 505mm 1467mm x 1217mm (4) Back Panels Front Panels 10x8 Floor Plan position position 1220mm 585mm 1220mm 1220mm 610mm 610mm 1220mm Single...
- Page 3 Door and Front Windows position options Side Opening Window (LEFT) Glazing Units position option (610mm) Panel Front Left Side Bottom Floor Plan Panel Single Door Panel 1220mm 585mm 1220mm (LEFT) Door Position (LEFT) Side Window Glazing Units Opening position (610mm) (LEFT) 610mm 610mm...
- Page 4 Building Parts: 10x8 Evolution My Den Building Parts Metal Roof Part ID Roof Section PT25544 1000mm Width 10ft Back Water PT25545 Roof Section Deflector Flashing PT25524 610mm Width Roof Section 1000mm Width Gable Frame PT25533 Standoff Roof Section PT25535 505mm Width...
- Page 5 Base Module Woodkits Fixing Kit Parts List required: 1. Base Module A - 1220mm x 2528mm (2) [ID: PT23585] 2. Base Module B - 585mm x 2528mm (1) Gable Bearers [ID: PT25386] Base Modules 3. Gable Bearers - 38mm x 2452mm (2) (For each end of the assebled base) [ID: PT23598] Base Module fixing...
- Page 6 Base Module Stages Base Module fixing Base Module fixing Base Module fixing Side 70mm Back 70mm 70mm Back Screws Screws Screws Pilot drill holes before fixing Side Front Side Front Front Alternate sides to screw together ID: PT23598 Gable Bearers are fitted on each side of Position the gable bearers each side to Pilot drill holes fully assembled base.
- Page 7 Floor Section Stages Base Module fixing Floor Stages Floor Stages 70mm Plinth Screws Back Pilot drill holes Side ID: 15603 ID: 15606 Front Base Module Side Lay and fix the Plinth Position the plinth into the top of lengths together at assembled base module Front the corner...
- Page 8 Floor Section Stages Floor Stages Floor Stages Back Side Back Front 50mm Screws Fix the Floors with Place the floor assembly screws in angled inside the plinth and position base module. Side Wall Panels Section Stages Parts List required: 1220mm 1220mm 1.
- Page 9 Wall Panels Section Stages Left Gable (High) Panel Stages Left Gable (High) Panel Stages Left Gable and Door Panel (LEFT) Position *Check the Side Opening Window (LEFT) position option floor plan for guidelines. ID: PT25534 Position and fix 50mm the plain gable panel (Left) Screws Lining...
- Page 10 Wall Panels Section Stages UPVC Door fixing UPVC Door fixing LEFT - Gable Cloaking Strip (CS) Front ID: PT21078 ID: 19503 50mm Screws Side Pilot drill holes Side before fixing (LEFT) Front (LEFT) Position and fix 80mm the gable Position and fit the UPVC Door Fix and secure the UPVC Door Cloaking Strip is used to fix section to the door panel (LEFT)
- Page 11 Rear Wall Panels Section Stages 1220mm 585mm 1220mm Parts List required: 1. Back Panel 1220mm LEFT (1) and RIGHT (1) Lining Flush Lining Flush Lining Flush 2. Back Panel 585mm (1) 3. Rear Cloaking Strip (2) 60mmx16mmx2012mm Panel Position Diagram Rear 16mm 16mm...
- Page 12 Rear Wall Panels Section Stages Back Panel (CENTRE) Stages Back Cloaking Strip fixing Back Panel (RIGHT) Stages ID: PT25545 Align and fix the Back Panel ID: PT21078 50mm Screws ID: PT25524 Position and fix 50mm Pilot drill holes the second Back before fixing Screws Back...
- Page 13 Gable Wall (RIGHT) Panel Stages Right Gable (Low) Panel Stages RIGHT - Gable Cloaking Strip (CS) Side Opening Window (RIGHT) fixing ID: PT25522 ID: PT21078 Front 50mm 50mm 50mm Screws Screws Screws Pilot drill holes Pilot drill holes Back before fixing before fixing Position and fix ID: PT25535...
- Page 14 Door on the Left Panel Stages Bottom Panel Stages Glazing Unit fixing Bottom Panel Stages ID: PT25547 Front ID: PT25547 Secure the Bottom Panel *Check the Front Window Panels position option (LEFT or RIGHT). 50mm Screws Position and align the Glazing Unit Check the corner gap of panel Front...
- Page 15 Top Panel Stages Top Panel Stages Glazing Unit fixing Glazing Unit Fix and secure Check the corner fixing the Top Panel gap of panel 70mm ID: PT20322 Screws ID: PT18490 Front 50mm Front Screws Position the Top Pilot drill holes Panel to the top Pilot drill holes before fixing...
- Page 16 Window Frame Cloaking Strip (CS) REAR - Roof Stand-Off Frame (SOF) GABLE - Roof Stand-Off Frame (SOF) ID: PT21078 Position and fix the Gable Frame 44mm x 27mm x 2590mm ID: PT21078 Back Position and fix the Rear Frame. 44mm x 27mm Side x 3060mm Back...
- Page 17 Roof Section Stages Parts List required: 1. Metal Roof Section L2920mm x W610mm - (1) [ID: 21192] 2. 115mm Metal Roof Screws Floor Plan Rear Side Side Side (Left) (Right) (RIGHT) Front Front of Building Roof Section Stages Roof Section Stages Roof Section Stages Roof section Roof sections...
- Page 18 Roof Section Stages Roof Section Stages Metal Roof Cross-Section Diagram Only 1 screw is required to hold the position of 115mm Metal the roof. Roof Screw Metal Roof ID: 21192 Wall 115mm Metal Panels Roof Screws Ensure the 115mm metal roof screws 115mm Metal Ensure the 115mm metal roof screws is align fix through to the wall panels...
- Page 19 Roof Section Stages Roof Section Stages Roof Section Stages Roof Section Stages 505mm Back 1m Wide 115mm Metal Wide Roof Screws ID: 21148 ID: 21140 ID: 21140 115mm Metal Side * Use Step ladder when * Use Step ladder when Roof Screws Back fixing the roof sections,...
- Page 20 Roof Section Stages Monopitch Ridge Flashing Stages ID: 21181 25mm Metal Roof Screws Front Position and fix the Monopitch Ridge Flashing to the front of roof sections. These are the same lenghts of water deflector flashing UPVC Single Door Glazing Unit fixing UPVC Single Door Glazing Unit fixing UPVC Single Door Glazing Unit fixing Rubber...
- Page 21 UPVC Single Door Glazing Unit fixing UPVC Single Door Glazing Unit fixing UPVC Door Frame and UPVC Beading UPVC Door Frame Front UPVC Beading Door Glazing Insert the rubber packing strip to the top to secure the ID: 19655 glazing unit. Add a Position the bottom UPVC couple of rubber fittings if necessary...
- Page 22 Silicone Sealant - optional Silicone Sealant - optional Silicone Selant - optional * Silicone sealant is not provided with the building. Repeat previous stage The window frames can also be sealed with Silicone sealant can be added around where silicone sealant silicone sealant around the edges where the the edges of the window frames is applied.
- Page 23 Internal Cover Trims Internal Cover Trims Side Window Architrave Detail Position and fit Window the D Mould strips frames to cover the join ID: 21084 between the Add the side and bottom Window window frame. battens window architrave using Secure the strips panel pins.
- Page 24 Internal Cover Trims Internal Cover Trims Internal Cover Trims Cut to size Fix the skirting boards Fix the cladding cover around the top and strips over the joins in bottom of the panels. the internal cladding ID: 21084 Cut to lenght and fix boards with Panel in place with Panel Fix the cladding cover...
