Project Timber Evolution My Den Building Instructions page 11

Side
(RIGHT)
27 Back Panels Position
74mm
1220mm
Back Panel (LEFT)
REAR - Wall Panels Section Stages
74mm
Back Panel
LEFT (1220mm)
Rear
ID: PT25544
28
Angle
screw
at top
50mm
Screws
Pilot drill holes
1220mm
before fixing
Back Panel (Right)
1220mm
Lining Flush
16mm 16mm
1146mm
Back Panel
RIGHT (1220mm)
Diagram
ID: PT25545
Back Panel Stages
ID: PT25544
Back
Align and fix
the back plain
(LEFT) panel
1220mm
Parts List required:
1. Back Panel 1220mm
LEFT (1) and RIGHT (1)
Lining Flush
2. Rear Cloaking Strip (1)
60mmx16mmx2012mm
Panel Position Diagram
1146mm 74mm
Side
(Left)
Diagram
29 Back Panel Stages
Gap for guttering
at top
ID: PT21077
Side
(RIGHT)
Position and fix the
Back Cloaking Strip (CS)
60mmx16mmx2012mm
Rear
Side
(Right)
Front of Building
50mm
Screws
Back
Pilot drill holes
before fixing
