Project Timber Evolution My Den Building Instructions page 21

69 Internal Cover Trims
Position and fit
the D Mould strips
to cover the join
between the
window frame.
Secure the strips
with panel pins.
40mm x 11mm
x 1766mm
ID: 21083
72 Internal Cover Trims
Fit the edge
frames around the
door frame using
Panel Pins
ID: 21083
Internal Cover Trims
70
Slide and fit the side
window batton to the
gap down the window
frame and secure with
50mm screws.
Side Window
Batton
28mm x 28mm
x 1766mm
Pilot drill holes
before fixing
73 Internal Cover Trims
Fix the skirting boards
around the top and
bottom of the panels.
Cut to lenght and fix
in place with Panel
Pins
ID: 21083
Internal Cover Trims
71
ID: 21083
74 Internal Cover Trims
Fit the edge frames
around the opening
window frame using
panel pins
ID: 21083
Fix the cladding cover
strips over the joins in
the internal cladding
boards with Panel
Pins
ID: 21083
