Printing Labels (IPL)

Creating a Label File

In order to test whether the printer has been correctly installed and
confi gured, you can print a simple label fi le. Th e fi le listed below is a text
fi le containing IPL commands created in a text editor, such as Windows
Notepad.
For further information regarding IPL and IPL commands, please
consult the IPL Programming Reference Manual.
<STX><ESC>C<ETX>
<STX><ESC>P<ETX>
<STX>E4;F4;<ETX>
<STX>H0;o102,51;f0;c25;h20;w20;d0,30;<ETX>
<STX>L1;o102,102;f0;l575;w5;<ETX>
<STX>B2;o203,153;c0,0;h100;w2;i1;d0,10;<ETX>
Edit/create Code 39 bar code fi eld 2 with interpretive fi eld enabled
<STX>I2;h1;w1;c20;<ETX>
<STX>R;<ETX>
<STX><ESC>E4<ETX>
<STX><CAN><ETX>
<STX>THIS IS THE SAMPLE LABEL<CR><ETX>
<STX>SAMPLE<ETX>
<STX><ETB><ETX>
Note: Th e line breaks in the preceding example are shown
for formatting purposes only and do not necessarily represent
carriage returns.
Save the fi le under a suitable name, for example
EasyLAN User's Guide
Chapter 5 — Basic Operations (Fingerprint and IPL)
Edit/create human-readable fi eld 0
Save format and exit to Print mode
Select Advanced mode
Enter Program mode
Erase format 4, create format 4
Edit/create line fi eld 1
Create interpretive fi eld
to go with bar code fi eld 2
Access format 4
human-readable fi eld 0
Data for bar code fi eld 2
ipltest.txt
Erase all data
Data for
Print
.
