More information about confi guration settings can be obtained by
printing a test label.
Also check on the printer's home page (Confi guration [TCP/IP]) that
the net1 TCP Port Number is correct (default 9100).

Network Card Not Responding

Connection to the Network

1 Check the network LED indicator at the back of the printer. Th ere
should be:
a) a green light fl ashing to indicate network activity.
b) a solid yellow background light if connected to a 100 Mbps
network, or if the network card is associated with an access point
(wireless only). Note that there is no background light indication
provided for 10 Mbps wired networks.
2 Check that the network cable connection at the back of the printer is
connected correctly.
3 Check that the cable connecting to the network is not of "crossover"
type. It has to be a straight "pin to pin" connection.

Internal Cabling

Authorized personnel only!
1 Check that the internal network extension or antenna cable and light
guide are properly connected to the EasyLAN optional board.
2 Check that the EasyLAN optional board is properly inserted in the
connector on the printer's CPU board.

Verifying IP Address

In the user's guide for your printer, you will fi nd information on how
to print test labels in the chapter "Setting Up the Printer". Print the
network test label and fi nd the IP Address fi eld. If the IP address is set
to 0.0.0.0, the network card has not received a IP address. Verify the IP
SELECTION setting under the NETWORK menu in the Setup Mode.
See the EasyLAN Interface Kit Installation Instructions for information on
various methods for setting the IP address automatically or manually.
EasyLAN User's Guide
Chapter 7 — Troubleshooting
95
