Setting sub-menu

"Setting" sub-menu is used to view and change settings for the following functions: Recording,

Metering, Communication interface, Relay application, and Monitoring. In this section, we

show the "Setting method for elements, switches, and list selection", "Protection setting", and

others. Furthermore, this section describes the confirmation of setting, and the "On/Off"

function that is used to hide some unnecessary settings.

Note: The meaning of settings and their setting process are beyond the scope of this

section. The figures in this chapter are examples only. The user should confirm

setting values after their values are changed.

Setting method

In "Setting" sub-menu, four setting modes are provided as follows:

Element Setting Mode

Switch Setting Mode

List Selection Mode (items selection)

Signal Selection Mode (signal selection)

Element Setting Mode: The "Element Setting Mode" is used for setting

numerical values. For each setting, the setting name, setting value and the

unit are displayed in two lines. Figure 12.5-1 provides an example of the

element setting mode.

Before Changing Setting

Figure 12.5-1 Example of Element Setting Mode

To begin the setting process, press the key ENTER. Once the setting has been

changed, the [*] mark will appear alongside the name of the setting. Once the

change is canceled or confirmed, the [*] mark will disappear automatically. For

the setting of a value, follow the steps as shown in Figure 12.5-2

After Changing

6F2S1915 (0.46)

GRZ200 (Soft 031 & 032)
