2
INSTALLATION
Antenna installation
D Antenna location
To obtain maximum performance from the transceiver, select
a high-quality antenna and mount it in a good location. A non-
radial antenna should be used when using a magnetic mount.
Roof-mount antenna
(Drill a hole or use a magnetic mount.)
Gutter-mount antenna
12
D Antenna connector
The antenna uses a PL-259 connector.
• PL-259 CONNECTOR
Trunk-mount
antenna
Slide the coupling ring
down. Strip the cable
jacket and soft solder.
Strip the cable as
shown at right. Soft sol-
der the center conduc-
tor.
Slide the connector
body on and solder it.
Screw the coupling ring
onto
body.
Coupling ring
the
connector
30 mm
10 mm (soft solder)
10 mm
Soft
solder
1–2 mm
solder solder
3
(10 mm
⁄
in)
8
