Aux Returns (return channels)

Aux Returns (return channels)
This section shows you which return channel parameters are affected by copy through
scenes.
Config sections
This section shows the configuration processing area parameters copied through
scenes.
DL431 Mic Splitter
input card
Item
1
2
3
4
5
6
* Depends on swap status.
** Only when sourced from a DL431 Mic Splitter.
Comp./Output Dyn
Not applicable.
PRO1 Live Audio System
Operator Manual
3
Control
stage box control knob*
48V switch**
Filter switch (not shown in
GUI diagram above)**
input zone switch
gain trim control knob*
delay control knob
5
1
2
Parameter
Remote amplifier level
48V phantom voltage on/off
30Hz filter in/out
Input zone in/out
Digital input trim
Delay time
527
4
5
1
3
6
