Stereo chorus

Emulation of dual stereo chorus but with having two units in one rack space.
1
Item
1
2
3
4
5
6
7
8
9
10
11
Element Function
lf cut control knob Low frequency cut control knob applies a 6dB/Oct
high pass filter to the input signal, in the range 10Hz
to 500Hz.
hf decay control Adjusts the ratio of decay for high frequency content,
knob between 0.1 and 1.0.
lf decay control Adjusts the ratio of decay for low frequency content,
knob between 0.1 and 10.0.
density control Increases the reflection density of the reverb tail,
knob between 0 and 100%.
decay control Adjusts the decay time relative to the room size, from
knob minimum to maximum.
size control knob Specifies the room size (also affects decay), from
small to large.
pre delay control Specifies the time before the reverb begins, between
knob 0ms and 200ms.
2 3 4
Element Function
in switch Switches the stereo chorus effect in/out.
stereo input Changes the operation to be stereo in and stereo out.
switch
Preset slow switch Sets a slow rate with minimal depth.
Preset deep switch Sets a slow rate with maximum depth.
Preset medium Sets a medium rate with minimal depth.
switch
Preset fast switch Sets a fast rate with minimal depth.
depth control Adjusts the amount of modulation applied to the pitch
knob in the range 0 to 100%.
rate control knob Adjusts the speed of modulation applied to the pitch
in the range 0.1Hz to 2Hz.
width control Adjusts the stereo spread of the output signal from
knob mono to stereo.
mix control knob Adjusts the dry/wet signal ratio.
Meters Input and output meters.
Chapter 16: Internal Effects
5 6 7 8 9
11
10
