316
Assignable audio processing
Mixing control assistance
Resilience

PRO1 general specifications

Sampling frequency
Latency delay
Dynamic range
Maximum voltage gain
Crosstalk at 1kHz
Crosstalk at 10kHz
Fader/pan cut off at 1kHz
Fader/pan cut off at 10kHz
Display screen
Dimensions
Net weight
Shipping weight
Power requirements
Operating temperature range
Storage temperature range
Appendix C: Technical Specification
4 x assignable stereo effects (each of these can
be reconfigured to generate 4 further GEQs,
making a total of 24 available on the console)
6 x auto-mutes
6 x surface POPulation groups
8 x VCA faders
8 x VCA groups
1000-scene snapshot automation
N+1 cable redundancy
96kHz
<2ms input to master (no compensation)
106dB, 22Hz to 22kHz (no pre-emphasis)
80dB inputs to subgroups and masters
86dB inputs to aux and matrix
-100dB physically adjacent input channels
-90dB physically adjacent input channels
-100dB
-100dB
1 x 15" daylight-viewable colour screen
PRO1 control centre: 586 mm wide x 570 mm
deep x 260 mm high (23.1" x 22.4" x 10.2")
DL251 I/O box: 5U x 200 mm deep
PRO1 control centre: 21.5 kg
DL251 I/O box: 10 kg
Touring (in flight case): 97.50 kg
Install (in carton): 28.70 kg
100V to 240V a.c. ±10%, 50 to 60Hz
+5°C to +45°C
-20°C to +60°C
