Matrix mixer

The matrix mixer is an eight mono I/O device with discrete metering for each input and
output. The display of the matrix mixer comprises controls that duplicate the
equivalent ones on the control surface and can be used as an alternative method of
operation. You can link the output EQ settings across channels and also link odd and
even outputs as a stereo pair, which is a GUI-only function.
Unlike the other internal effects, the matrix mixer has two screens (input and output),
which require specific navigational methods (see "Navigating the input and output
screens" on page 156). Both screens provide an overview of the other to save you
having to navigate between them in order to obtain incidental information.
Note: The global tap option does not apply to the matrix mixer.
Element(s) Function
lf cut controls This low frequency control knob applies a 6dB/Oct
high pass filter to the delay and optionally feedback
signal (by switching on the post fb switch below).
The default is post-delay and pre-feedback. Range is
from 10Hz to 500Hz.
hf cut controls This high frequency control knob applies a 6dB/Oct
low pass filter to the delay and optionally feedback
signal (by switching on the post fb switch below).
The default is post-delay and pre-feedback. Range is
from 200Hz to 20kHz.
mix control knob Adjusts the dry/wet signal ratio.
Meters Input and output meters.
