Midas PRO1 Owner's Manual page 541

Inputs (input channels)
Item
7
8
9
10
11
12
Aux Sends (1 to 16)
This section shows the aux send parameters copied through scenes.
Note: Only aux sends 1 to 8 are shown above, but this is typically the same for all of
the 16 aux sends.
Item
1
2
3
4
5
6
PRO1 Live Audio System
Operator Manual
Control
SLOPE pushbutton
low pass control
knob
/[IN] switch
/[IN] switch
high pass control
knob
SLOPE pushbutton
5
6
Control
ON switch
level/pan control
knob
PRE switch
level control knob
On switch
MINUS switch
Parameter
Low pass filter slope 6dB or 12dB
Low pass filter frequency
Low pass filter in/out
High pass filter in/out
High pass filter frequency
High pass filter slope 12dB or 24dB
Parameter
Bus send on/off
Bus level, or pan when bus is linked
Pre-fader on/off
Bus level
Aux bus send on/off — only available when aux
bus is in group mode
Aux bus send mute on/off — only available when
aux bus is in mix minus mode
523
1
2
3
1
4
3
As per
bus sends
1-2 above
