Hall reverb
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
PRO1 Live Audio System
Operator Manual
Element Function
input meter Two adjacent 11-LED columns — one each for left and
right — comprise the input meters.
mix control knob Adjusts the dry/wet signal ratio.
modulation Specifies the combined rate and depth of modulation
control knob applied the reverb tail.
contour time Controls the time over which the reflection density
control knob increases during the initial portion of the reverb tail,
between fast and slow.
contour Controls the time over which the reflection density
envelope control increases during the initial portion of the reverb tail,
knob between fast and slow.
lf x-over control Specifies the cross-over frequency for the low
knob frequency decay (lf decay), in the range 20Hz –
500Hz.
in switch Switches the Plate Reverb effect in/out.
audition button This momentary-action button triggers a short
internally generated sound to aid reverb evaluation
(as a check).
output meter Two adjacent 11-LED columns — one each for left and
right — comprise the output meters.
hf cut control High frequency cut control knob applies a 6dB/Oct
knob low pass filter to the input signal, in the range 200Hz
to 20kHz.
lf cut control knob Low frequency cut control knob applies a 6dB/Oct
high pass filter to the input signal, in the range 10Hz
to 500Hz.
hf damp control High frequency damping, progressively reduces the
knob high frequency content over time, in the range 1kHz
to 20kHz.
lf decay control Specifies the ratio of decay for low frequency content,
knob in the range 0.5 – 2.0.
diffusion control Increases the density of both the early reflections and
knob reverb tail, between 0 and 100%.
decay control Adjusts the decay time relative to the room size, from
knob minimum to maximum.
size control knob Specifies the room size (also affects decay), from
small to large.
pre delay control Specifies the time before the reverb begins, between
knob 0ms and 200ms.
