Midas PRO1 Owner's Manual page 183

About the control group screens
Item
1
2
3
4
5
6
>> To program a group at the GUI screen
1
Open the screen of the desired control group. For example, if you want to
program a VCA group, open the VCA Groups screen.
2
Click the desired group. For example, VCA1.
3
Click the channels that you want to add to the group.
4
Click ADD. The channels will be moved to the group member panel.
If you want to remove any members from the group, click the channels that you want
to remove from the group (group member panel). Then, click REMOVE. The channels
are moved back to their respective lists.
PRO1 Live Audio System
Operator Manual
Control Function
Group member These group type-dependent lists let you choose
selection lists which inputs, returns, auxes, matrices and masters
you want as members in the selected group. If
necessary, use the slider on the right of a panel to
access all non-members.
You can add more than one member at once by using
the Ctrl and Shift keys on the keyboard. Shift will
select a range of members and Ctrl will act as an
individual toggle.
Group member Shows the current group members and lets you
panel
Name field Name of selected group.
Group member List of the current members of the selected group.
panel
ADD button Moves the non-members (selected in the group
member selection lists) to the group member panel,
adding them to the group.
REMOVE button Moves the members (selected in the group member
panel) back to their respective group member
selection lists, removing them from the group.
165
