Midas PRO1 Owner's Manual page 262

244
The AES3 sync input and output connectors are for synchronisation with external
devices that can transmit/receive a 96kHz AES3 signal. They accept a female XLR plug
and male XLR plug, respectively.
The two pairs of AES3 input and output connectors are for synchronisation with external
devices that can transmit/receive a 96kHz AES3 signal. They accept a female XLR plug
and male XLR plug, respectively.
IEC connector for mains power supply.
1
2
3
4
1. N/A. 2.
Chapter 29: Connections
N/A. 3. Ground. 4. 12V.
PRO1 Live Audio System
Operator Manual
