Selecting the surround mode

Selecting the surround mode
The Surround Mode section of the Show tab lets you
select the type of surround mode that the PRO1 uses. For
information, see "Selecting the surround mode" on
page 225 and "Surround panning" on page 98.

Setting the time and date

The Date and Time section of the Configuration tab lets
you change the PRO1's time and date.
>> To set the time and date of the PRO1
1
At a GUI screen, choose home
2
In the Date and Time section of Configuration Preferences, click SET.
3
In the time and date window, enter the time (hours
and minutes) and date. Make sure you enter the
time correctly, according to the currently
configured Format, that is, 12-hour (a.m. or p.m.)
or 24-hour.
4
Click OK.

Setting the user interface preferences

The User Interface section of the User tab lets you set
some of the PRO1's operating parameters to suit your own
preferences.
• Display Rotary Values — the current value of a
parameter, adjusted via a control knob or fader, can be
displayed as a numerical value on the GUI or LCD select
button, respectively. See "Values displayed on touch
(control knob/fader)" on page 40.
• Fast Zone Delay Control — choosing this option
means that you place the delay control for the inputs
onto the surface controls. To do this you have to cycle
the gain SWAP button (see "Using gain swap" on
page 257) through digital gain, analogue gain and then
delay. Without selecting this option, the inputs delay
control is a GUI only feature.
• Input Select Follows Solo — when you solo an input channel, such as an aux
return, this channel is automatically selected.
• Output Select Follows Solo — when you solo an output channel, such as a matrix,
this channel is automatically selected.
• Automate Paging — choose this option to store channel paging in automation. So
that, on scene recall, the control surface (channels assigned to it) will revert to the
state it was when the scene was last saved. When unselected, scene recall does not
affect channel paging.
• Touch Navigation of Detail Area — choose this option to navigate the local
processing (detail) area on the control surface (right of the GUI screen) to the GUI
processing area when one of its touch-sensitive controls is operated.
