Chapter 30: Input Channels
By default, all of the input channels are mono, although any two adjacent channels (odd
left and even right) can be linked to form a stereo pair. The order of processing in the
signal path of both channel types is basically the same.
The order of the descriptive sections in this chapter loosely follows the signal path taken
by the input channels. However, this varies according to signal processing order and
the operation of certain controls.

Input channel routing

The diagram right shows the default
signal path, on which the structure of
this chapter is based. This chapter will
explain each of these groups of
controls, showing the pertinent controls
on both the control surface and GUI.
PRO1 Live Audio System
Operator Manual
Mic splitter remote controls
Channel configuration
Gain and filter controls
Order can be
swapped by
pressing the
C/O button (see
page 257)
247
(see page 254)
(see page 252)
(see page 254)
Direct output
(see page 258)
Gate
(see page 264)
Compressor
(see page 260)
Insert controls
(see page 266)
Equaliser
(see page 266)
Aux controls
(see page 269)
Matrix controls
(see page 269)
Master controls
(see page 271)
