RT540E SERVICE MANUAL
Lube Point
Item
Description

Turntable

Turntable Gear
20
Box
Turntable Gear
21
and Drive Pinion
Turntable Swivel
Lock Pin
21a

Turntable

22
Bearing
NOTE: Rotate the turntable 90° and apply grease to fittings. Continue rotating 90° and grease the fittings until the whole
bearing is greased.
GROVE
Figure Approved
No. Lubricant
GL-5
Extended
Figure 9-6 Service Interval
Gear Lubricant
A6-829-012964
EP-OGL
Open Gear
Figure 9-6
Lubricant
A6-829-102971
EP-OGL
Not shown
Open Gear
Lubricant
A6-829-102971
EP-MPG
Extreme
Pressure
Figure 9-6
Multipurpose
Grease
A6-829-003477
Published 4-20-2015, Control # 502-01
Lube
Lube Interval
Capacity
• Check and fill every
50 hours
4.0 l
• Drain and fill after
4.25 qt
first 250 hours and
every 500 hours or
12 months thereafter.
Coat all
500 hours or 6 months
teeth
Coat pin 500 hours or 6 months
Until
grease
extrudes
the whole 500 hours or 6 months
circumfer-
ence of the
bearing
LUBRICATION
Application
Use dipstick. If no
dipstick, fill to top of
case.
Spray on
Spray on
2 grease fittings at
the front of the
turntable
9
9-15
