HYDRAULIC SYSTEM
9
18
28
8492
Item
1
Pilot Supply Relief Valve
2
Gauge Port- GP4
3
Swing Brake Relief Valve
4
Solenoid Valve - Swing Brake
5
Solenoid Valve - Swing Brake Release
6
Solenoid Valve - Pilot Supply
7
Gauge Port - GP1
8
Pilot Supply Port - PS
9
Drain - D2
10
Port 2B - Swing Left
11
Port 2A - Swing Right
12
Swing Directional Valve
13
Drain Port - D4 (Swing Motor Pilot Supply)
14
Drain Port - D6 (Hoist/Tele/Lift valve Pilot Supply)
2-34
8
20
7
2
Description
Published 4-20-2015, Control # 502-01
29
10
22
24
12
11
13
14
16
15
19
17
1
17
Item
15
Drain Port - D7 (Swing Brake/Lift Cylinder Pilot)
16
Drain Port - D3 (Plugged)
17
Gauge Port - GP2
18
Gauge Port - GP5
19
Drain Port - D1
20
Gauge Port - GP3
21
Swing Brake Release Port - SBR
22
Drain Port - D5
23
Swing Brake Supply Port -SBS
24
Tank Port
25
Gauge Port - GP6 (Plugged)
26
Gauge Port - GP8 (Plugged)
27
Proportional Two Position Two Way Solenoid
28
Steering Priority Valve
29
Steer Circuit Load Sense Relief
RT540E SERVICE MANUAL
23
21
11
27
6
28
3
5
4
FIGURE 2-16 continued
