RT540E SERVICE MANUAL
Fault Code
GROVE
5033 Rear steer right switch input
5034 Park brake release switch input
5035 2 wheel drive switch input
5036 Differential lock switch input
5037 Brake pedal switch input
5038 Retarder / Thelma brake switch
5040 Outrigger extend switch input
5041 Outrigger retract switch input
5042 Cabin lower switch input
5043 Cabin raise switch input
5050 Crane functions switch input
5051 Boom lights switch input
5052 Bypass hoist limiter switch input
5053 Bypass RCL inside switch input
5054 Bypass RCL outside switch input
5055 Bypass Derricking switch input
5056 Aircraft warning light switch input
5057 Working light switch input
5058 Rotating flashing light switch
5059 High beam flasher switch
5060 Air Condition Switch (Carrier)
5061 Air Condition Switch (Superstructure)
5100 Enable Extend switch input
5101 Enable Retract switch input
5102 Enable Aux Hoist switch input
5103 Enable Main Hoist switch input
5104 Enable Derricking switch input
5105 Enable Slewing switch input
5106 Enable Telescoping switch input
5107 Enable Freeswing switch input
5108 Enable Jib switch input
5109 Jib Identity
5110 Jib Remote Control down switch input
5111 Jib Remote Control up switch input
5112 Cab Tilt Down switch input
5113 Cab Tilt Up switch input
5150 Left Joystick Deadman input
5151 Right Joystick Deadman input
Published 4-20-2015, Control # 502-01
Component Description
ELECTRIC SYSTEM
3-17
3
