ELECTRIC SYSTEM
3-22
Fault Code
5950
Auxiliary Hoist Indenitifier input
5951
New York House Lock Pin Bolted input
5952
New York House Lock Locked input
5953
New York House Lock Unlocked input
5954
Counterweight Left Unlock input
5955
Counterweight Right Unlock input
5956
Counterweight Left Lock input
5957
Counterweight Right Lock input
5958
Counterweight Left Bottom Proximity Switch input
5959
Counterweight Right Bottom Proximity Switch input
5960
Counterweight Left Top Proximity Switch input
5961
Counterweight Right Top Proximity Switch input
5962
Hoist Limiter (A2B) Switch input - Stop
5963
Steering Filter switch input
5964
Flow indicator steering circle 1
5965
Flow indicator steering circle 2
5966
Air Filter switch input
5967
Cabin locked left switch input
5968
Cabin locked right switch input
5969
Bridge collision switch input
5970
Filter backpressure switch input 1
5971
Filter backpressure switch input 2
5972
Length Hydraulic pivot cylinder
5973
Auxhoist right locked
5974
Auxhoist left locked
5975
Auxhoist right unlocked
5976
Auxhoist left unlocked
5977
Auxhoist carrier retracted
5978
Counterweight installed input
5979
Counterweight in position input
5980
Counterweight position left analog input
5981
Counterweight position right analog input
5982
Derricking valve spool position analog input
5983
Slew left pressure analog input
5984
Slew right pressure analog input
5985
Hoist Limiter (A2B) Switch input - Slow
6000
PERM 24V voltage output
6001
Release LMI output
Published 4-20-2015, Control # 502-01
Component Description
RT540E SERVICE MANUAL
