SAFETY INFORMATION

MODEL SPECIFIC INFORMATION

The RT530E-2 on rubber load charts have a minimum radius
of 3 m (9.84 ft) with a load. Without a load, a radius of 2.5 m
(8.20 ft) is safe for 360 degrees on rubber. A radius of less
than 2.5 m (8.20 ft) must be avoided on rubber because of
backward stability considerations.

OVERLOAD INSPECTION

This information supplements the Rated Capacity Limiter
(RCL) manual supplied with each Grove crane.
When the RCL system has acknowledged an overload on
your crane, you must carry out specified inspections on the
crane.
These inspections apply only to overloads up to 50%. For
overloads of 50% or higher, crane operation must be
stopped immediately and Crane Care must be contacted for
corrective action.
T h e f o l l o w i n g i l l u s t r a t i o n s m a y n o t b e a n e x a c t
representation of your crane and are to be used for reference
only.
2-40
To avoid an accident caused by overload damage to
your crane:
• Perform the inspections outlined in this publication
for overloads up to 50%.
• Stop operating the crane and contact Manitowoc
Crane Care immediately for overloads of 50% and
higher.
NOTE:
Published 5-3-2016, Control # 555-02
RT530E-2 OPERATOR'S MANUAL
WARNING
Overload Hazard!
If your crane is equipped with CraneSTAR, an
overload warning will be posted to the web site for
review by the crane owner.
Overload warnings do NOT indicate real time
events! Warnings could be sent 24 hours (or more)
after the actual event.
