Axles - Manitowoc Grove RT530E-2 Operator's Manual

LUBRICATION
Lube Point
Item
Description

Axles

Axle Tech
6
Differentials
NOTE: Lube level close enough to the hole to be seen or touched is not sufficient. It must be level with the hole.
When checking lube level, also check and clean housing breathers.
CAUTION: Use of non-approved lubricant may damage components and/or invalidate published lubricant intervals.
CAUTION: If the makeup amount is substantially more than 0.23 liter (0.5 pint), check for leaks.
Axle Tech
Planetary Hubs
9
and Wheel
Bearings
CAUTION: Use of non-approved lubricant may damage components and/or invalidate published lubricant intervals.
5-8
Figure Approved
No. Lubricant
GL-5
Extended
As seen in
Service Interval
Figure 5-2
Gear Lubricant
6829012964
GL-5
Extended
As seen in
Service Interval
Figure 5-2
Gear Lubricant
6829012964
Published 5-3-2016, Control # 555-02
RT530E-2 OPERATOR'S MANUAL
Lube
Lube Interval
Capacity
• Check level every
500 hours or 3
months
20.8 l
(44 pt)
• Drain and fill every
4000 hours or 2
years
• Check level every
500 hours or 3
months
3.1 l
(6.5pt)
• Drain and fill every
4000 hours or 2
years
Application
Fill to bottom of hole
in housing on the
steer cylinder side
Fill to the bottom of
the level hole in the
housing with the fill
plug and the oil level
mark horizontal.
