Manitowoc Grove RT530E-2 Operator's Manual page 95

RT530E-2 OPERATOR'S MANUAL
Stowing and Parking
When parking the crane, do the following:
Tipping Hazard!
Never park crane near holes, on rocky surfaces, or on soft
spots. This may cause crane to overturn, resulting in
injury or death to personnel.
1. Remove the load from the hook.
2. Remove or stow boom extensions if so equipped.
3. Fully retract all boom sections.
4. Lower the boom to normal travel position.
5. Engage the swing brake and swing lock pin.
6. Retract all jack cylinders and outrigger beams.
7. Park the crane on a stable surface.
8. Apply the parking brakes and if necessary, chock
wheels.
9. Ensure all operating controls are in neutral position.
GROVE
DANGER
Published 5-3-2016, Control # 555-02
OPERATING CONTROLS AND PROCEDURES
10. Shut down engine following proper procedures specified
in this Operator Manual and the applicable engine
manual.
11. Remove the keys.
12. Close and lock, if applicable, all windows, covers, and
doors.
13. Turn battery disconnect to OFF position if machine will
be inactive for over 24 hours (Figure 3-6).
Unattended Crane
Tipping Hazard!
Changing weather conditions including, but not limited to,
wind, ice accumulation, precipitation, flooding, lightning,
etc. should be considered when determining the location
and configuration of a crane when it is to be left
unattended.
Failure to comply with these instructions may cause death
or serious injury.
The configuration in which the crane should be left while
unattended shall be determined by a qualified, designated
individual familiar with the job site, configuration, conditions,
WARNING
3
3-25
