LUBRICATION
Lube Point
Item
Description

Boom

Upper Lift
25
Cylinder Pin
Hook Block
29
Swivel Bearing
Hook Block
30
Sheaves
Telescope
31 Cylinder Wear
Pads
32 Side Wear Pads
Boom Section
33 Upper Wear
Pads
Boom Section
34 Lower Wear
Pads
Extend Cable
35
Sheaves
Retract Cable
36
Sheaves
NOTE: Lubricate items more frequently than interval indicated in table if environmental conditions and/or operating
conditions necessitate.
5-18
Figure Approved
No. Lubricant
EP-MPG
Extreme Pressure
Figure 5-7
Multipurpose
Grease
6829003477
EP-MPG Extreme
Pressure
Figure 5-7
Multipurpose
Grease
6829003477
EP-MPG Extreme
Pressure
Figure 5-7
Multipurpose
Grease
6829003477
EP-MPG Extreme
Pressure
Figure 5-7
Multipurpose
Grease
6829003477
EP-MPG Extreme
Pressure
Figure 5-7
Multipurpose
Grease
6829003477
EP-MPG Extreme
Pressure
Figure 5-7
Multipurpose
Grease
6829003477
EP-MPG Extreme
Pressure
Figure 5-7
Multipurpose
Grease
6829003477
EP-MPG Extreme
Pressure
Figure 5-7
Multipurpose
Grease
6829003477
EP-MPG Extreme
Pressure
Figure 5-7
Multipurpose
Grease
6829003477
Published 5-3-2016, Control # 555-02
RT530E-2 OPERATOR'S MANUAL
Lube
Lube Interval
Capacity
Until
grease 500 hours or 3 months
extrudes
Until
grease 250 hours or 3 months
extrudes
Until
grease 250 hours or 3 months
extrudes
Thoroughly Every boom teardown
coat or 125 hours/3 months
Thoroughly
coat all
areas the 250 hours or 3 months
wear pad
moves on
Thoroughly
coat all
areas the 50 hours or 1 week
wear pad
moves on
Thoroughly
coat all
areas the 50 hours or 1 week
wear pad
moves on
Until
grease 250 hours or 3 months
extrudes
Until
grease
250 hours or 3 months
extrudes
Application
1 grease fittings
1 grease fitting
4 grease fittings - 35
Tons
3 grease fittings - 35
Tons
2 places by brush
Extend boom for
access through
holes
12 places by brush;
with boom in
extended position
6 places by brush;
with boom in
extended position
through access
holes
3 places by brush;
with boom in
extended position
3 grease fittings
Extend boom for
access through
holes
4 grease fittings
