RT530E-2 OPERATOR'S MANUAL
Turntable Lock Control (Pin Type)
The Swing Lock Pin Control Handle (13) (Figure 3-11) is
located beside the front console on the right side of the cab.
T h e p u r p o s e o f t h e s w i n g l o c k p i n i s t o l o c k t h e
superstructure in position directly over the front for pick and
carry loads. When the control handle is pushed down and
the superstructure is directly over the front, the swing lock
pin drops into the socket on the carrier frame, locking the
GROVE
OPERATING CONTROLS AND PROCEDURES
superstructure in place. When the control handle is pulled
up, the pin is pulled out of the socket, unlocking the
superstructure.
Sensors
There is a Temperature Sensor (12) and a Brightness
S e n s or ( 11 ) ( F i g ur e 3-11 ) . T h e B r i g h tn e s s S e ns o r
automatically adjusts the brightness of all displays.
Published 5-3-2016, Control # 555-02
3
3-27
