Hoist - Manitowoc Grove RT530E-2 Operator's Manual

LUBRICATION
Lube Point
Item
Description

Hoist

45 Main Hoist
46 Auxiliary Hoist
NOTE: Line up the Fill/Drain Plug with the upper cutout hole (A). Let hoist sit idle for 20 minutes for an accurate reading.
Ensure hoist is level and oil temperature is 21°C ±11°C (70°F ±20°F). If oil level is not visible in sight glass, the
hoist may be under filled. Oil escaping from vent plug is an indication the hoist may be over filled. If hoist is over
filled, move the Fill/Drain Plug to the lower cutout hole (B) and drain until oil level falls within the sight glass.
Cable Follower
47
(Arms)
NOTE: Lubricate more frequently than interval indicated in table if environmental conditions and/or operating conditions
necessitate.
5-22
Figure Approved
No. Lubricant
AGMA
Extreme
Figure 5-9 Pressure Gear
Lubricant
6829100213
AGMA
Extreme
Figure 5-9 Pressure Gear
Lubricant
6829100213
EP-MPG
Extreme
Pressure
Figure 5-9
Multipurpose
Grease
6829003477
Published 5-3-2016, Control # 555-02
RT530E-2 OPERATOR'S MANUAL
Lube
Lube Interval
Capacity
• Check and fill every
50 hours or weekly
5.2 l
• Drain and fill every
(5.5 qt)
1000 hours or 12
months
• Check and fill every
50 hours or weekly
5.2 l
• Drain and fill every
(5.5 qt)
1000 hours or 12
months
Thoroughly
250 hours or 3 months
coat
Application
Oil level must be
visible in the sight
glass
Oil level must be
visible in the sight
glass
Spray on
